Запчасти Komatsu WA900-1LC A20008-UP ТЕРМОСТАТ СИСТЕМА ОХЛАЖДЕНИЯ

1

6215-11-6810

GASKET, HOUSING

1шт.

2

6215-61-6520

RETAINER, TUBE

1шт.

3

6215-61-6530

GASKET, WATER TRANSFER CONNECTION

1шт.

4

6215-61-7510

CONNECTION, WATER BYPASS

1шт.

5

07000-G3045

SEAL, O-RING

2шт.

6

6216-84-2510

BOLT (M10x1.50x20)

5шт.

7

6216-14-6880

BOLT (M10x1.50x10)

4шт.

8

6216-14-6810

BOLT (M12x1.75x20)

12шт.

9

01643-31232

WASHER, PLAIN (M12)

12шт.

|$9

6216-14-6120

HOUSING, THERMOSTAT ASSEMBLY

1шт.

10

6216-14-6820

PLUG, THREADED

1шт.

|$11

6216-14-6860

SEAL, O-RING

1шт.

11

6216-14-6830

PLUG, THREADED

1шт.

|$13

6216-14-6840

SEAL, O-RING

1шт.

12

600-421-6630

THERMOSTAT

3шт.

13

6216-14-6520

CONNECTION, WATER OUTLET

1шт.

14

6216-14-6530

CONNECTION, WATER OUTLET

1шт.

15

6162-13-6440

SEAL, THERMOSTAT

3шт.

16

6215-61-5110

HOUSING, THERMOSTAT

1шт.

17

6215-61-5170

CASE, THERMOSTAT

1шт.

18

6215-11-6150

PLATE, COVER

1шт.

19

6215-11-6820

GASKET, HOUSING

1шт.

20

6215-11-6830

GASKET, COVER PLATE

3шт.

21

6216-84-6560

BOLT (M10x1.50x35)

4шт.

22

07040-11409

PLUG, THREADED

3шт.

23

6216-74-6250

WASHER, SEALING

3шт.

24

01011-31025

BOLT (M10x1.50x25)

8шт.

25

6216-14-6870

PLATE, COVER

1шт.

26

6210-21-1971

GASKET, COVER PLATE

1шт.

27

6735-21-1910

PLUG, THREADED

1шт.

|$30

6735-21-1930

SEAL, O-RING

1шт.

28

6732-21-1960

PLUG, THREADED

1шт.

|$32

6215-81-9710

SEAL, O-RING

1шт.

29

6215-61-7521

TUBE, WATER TRANSFER

1шт.
