Запчасти Komatsu WA800-3LC K7-A ТОРМОЗНАЯ ГИДРОЛИНИЯ ПОЛ ЛИНИЯ (/) (заводской номер A-A ) OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

VALVE, TANDEM (SEE FIG. K4470-10A0 )

SN: A50001-A50024-UP

-1шт.

2

01435-01030

BOLT

SN: A50001-A50024-UP

6шт.

3

415-15-14331

ELBOW

SN: A50001-A50024-UP

4шт.

4

07002-12034

O-RING

SN: A50001-A50024-UP

8шт.

5

421-43-27860

UNION

SN: A50001-A50024-UP

2шт.

6

421-43-27870

UNION

SN: A50001-A50024-UP

2шт.

7

07108-20613

HOSE

SN: A50001-A50024-UP

1шт.

8

07108-20613

HOSE

SN: A50001-A50024-UP

1шт.

9

07108-20610

HOSE

SN: A50001-A50024-UP

2шт.

10

421-43-22690

BRACKET

SN: A50001-A50024-UP

1шт.

11

01435-01016

BOLT

SN: A50001-A50024-UP

4шт.

12

144-A74-1460

CLIP

SN: A50001-A50024-UP

2шт.

13

01435-01016

BOLT

SN: A50001-A50024-UP

2шт.

14

427-43-27631

TEE

SN: A50001-A50024-UP

4шт.

15

07002-12034

O-RING

SN: A50001-A50024-UP

4шт.

16

07042-30108

PLUG

SN: A50001-A50024-UP

2шт.

17

421-43-22942

SWITCH, STOP LAMP

SN: A50001-A50024-UP

1шт.

18

419-06-21121

SWITCH, TRANSMISSION CUT-OFF

SN: A50001-A50024-UP

1шт.

19

07108-20411

HOSE

SN: A50001-A50024-UP

2шт.

20

07108-20413

HOSE

SN: A50001-A50024-UP

2шт.

21

04434-52110

CLIP

SN: A50001-A50024-UP

4шт.

22

01435-01016

BOLT

SN: A50001-A50024-UP

2шт.

23

20R-62-11360

ELBOW

SN: A50001-A50024-UP

2шт.

24

07002-12034

O-RING

SN: A50001-A50024-UP

2шт.

25

07108-20307

HOSE

SN: A50001-A50024-UP

1шт.

26

427-43-27610

HOSE

SN: A50001-A50024-UP

1шт.

27

427-06-12440

BRACKET

SN: A50001-A50024-UP

1шт.

28

04434-52110

CLIP

SN: A50001-A50024-UP

1шт.

29

VALVE, SHUTTLE (SEE FIG. K4470-05A0 )

SN: A50001-A50024-UP

-1шт.

30

TUBE (SEE FIG. K4470-07A0 )

SN: A50001-A50024-UP

-1шт.

31

TUBE (SEE FIG. K4470-02A0 )

SN: A50001-A50024-UP

-1шт.

32

TUBE (SEE FIG. K4470-03A0 )

SN: A50001-A50024-UP

-1шт.
