Запчасти Komatsu WA800-3LC K-A ПОЛ Э/ПРОВОДКА DISPLAY LIGHTS OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

427-06-A2380

C OVER

SN: A50001--UP

1шт.

2

421-09-21410

SCREW, SEMS

SN: A50001--UP

2шт.

3

282 437 R91

SWITCH

SN: A50001--UP

1шт.

4

427-06-A2180

SWITCH

SN: A50001--UP

1шт.

5

426-06-A2210

LAMP ASSEMBLY, RED

SN: A50001--UP

1шт.

6

426-06-A2220

LAMP ASSEMBLY, YELLOW

SN: A50001--UP

1шт.

7

426-06-A2230

LAMP ASSEMBLY, ORANGE

SN: A50001--UP

1шт.

8

427-06-A2450

HARNESS, ECM PANEL

SN: A50001--UP

1шт.

9

MM 0 328

SCREW, MACHINE

SN: A50001--UP

8шт.

10

MM 0 370

NUT

SN: A50001--UP

8шт.

11

DECAL, F N R (SEE FIG. U0100-02A0 )

SN: A50001--UP

-1шт.

12

22T-051-5630

LED LIGHT, GREEN

SN: A50001--UP

3шт.

13

427-93-A1150

DECAL, DIAGNOSTICS

SN: A50001--UP

1шт.

14

427-93-A1120

DECAL, CONNECTION

SN: A50001--UP

1шт.
