Запчасти Komatsu WA800-3LC K7-A КОНДИЦ. ВОЗДУХА ВОЗДУХОВОД OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

425-07-21152

DUCT ASSEMBLY, AIR

SN: A50001--UP

2шт.

1

ND145820-9610

DUCT, AIR

SN: A50001--UP

1шт.

2

ND145820-8330

DUCT, AIR

SN: A50001--UP

1шт.

3

ND116730-0690

DAMPER

SN: A50001--UP

1шт.

4

ND116730-0700

DAMPER

SN: A50001--UP

1шт.

5

ND017732-4840

LEVER, CONTROL

SN: A50001--UP

1шт.

6

ND017732-4850

LEVER, CONTROL

SN: A50001--UP

1шт.

7

ND017732-4860

LEVER, CONTROL

SN: A50001--UP

1шт.

8

ND017732-4870

LEVER

SN: A50001--UP

1шт.

9

ND116662-0640

SHAFT

SN: A50001--UP

1шт.

10

ND949008-0420

SCREW WITH WASHER, TAPPING

SN: A50001--UP

2шт.

11

ND913100-3081

SCREW WITH WASHER

SN: A50001--UP

2шт.

12

ND116632-0171

SPRING, HOLDING

SN: A50001--UP

8шт.

13

ND063700-6570

MOTOR

SN: A50001--UP

1шт.

14

ND949008-0780

SCREW WITH WASHER, TAPPING

SN: A50001--UP

1шт.

15

ND146625-2630

BUSHING

SN: A50001--UP

3шт.

16

ND246690-2930

CLAMP

SN: A50001--UP

1шт.

17

ND017773-0140

CLIP

SN: A50001--UP

1шт.

18

ND116662-4210

SHAFT

SN: A50001--UP

1шт.

19

ND949202-0940

BUSHING

SN: A50001--UP

1шт.

20

ND146522-6180

BRACKET

SN: A50001--UP

1шт.

21

ND909400-5161

SCREW, TAPPING

SN: A50001--UP

6шт.
