Запчасти Komatsu WA800-3LC J7-A АВТОМАТИЧ. СМАЗ. АВТОМАТИЧ. СМАЗКА СИСТЕМА ОСНОВНАЯ РАМА И ЕЕ ЧАСТИ

1

LUBE PUMP AND CONTAINER ASSEMBLY (SEE FIG. J4710-15A1 )

SN: A50001--UP

-1шт.

2

HA 7 870

HOSE (OIL PRESSURE INLET)

SN: A50001--UP

1шт.

3

WB 0 499

FITTING, ELBOW - 90 DEG.

SN: A50001--UP

1шт.

4

HA 7 285

HOSE (GREASE OUTLET)

SN: A50001--UP

1шт.

5

WB 0 466

FITTING, STRAIGHT

SN: A50001--UP

1шт.

6

HA 7 871

HOSE (OIL DRAIN TO TANK)

SN: A50001--UP

1шт.

7

WB 0 535

FITTING, ELBOW - 45 DEG.

SN: A50001--UP

1шт.

8

EJ 0 966

BRACKET, MOUNTING

SN: A50001--UP

1шт.

9

WA 4 726

FLAT WASHER - 3/8 IN (HARDENED)

SN: A50001--UP

8шт.

10

C 1 604

CAPSCREW - 3/8 IN - 16NC X 1 1/2 IN

SN: A50001--UP

4шт.

11

WB 0 268

FITTING, ELBOW - 90 DEG.

SN: A50001--UP

3шт.

12

FILTER, HYDRAULIC (SEE FIG. J4710-14A2 )

SN: A50001--UP

-1шт.

13

HA 5 843

HOSE

SN: A50001--UP

1шт.

14

C 1 601

CAPSCREW - 3/8 IN - 16NC X 3/4 IN

SN: A50001--UP

4шт.

15

PC 1 296

SWITCH, PRESSURE

SN: A50001--UP

1шт.

16

EJ 2 138

HARNESS, LUBE

SN: A50001--UP

1шт.

17

TG 2 562

CLAMP - 1/2 IN I.D.

SN: A50001--UP

2шт.

18

WB 2 763

DECAL

SN: A50001--UP

1шт.

19

HA 5 843

HOSE

SN: A50001--UP

1шт.

20

C 1 540

FLAT WASHER - 1/2 IN

SN: A50001--UP

6шт.

21

VC 1 387

CAPSCREW -1/2 IN - 13NC X 1 IN

SN: A50001--UP

6шт.

22

TR 9 441

CLAMP - 1 1/4 IN I.D.

SN: A50001--UP

1шт.

23

MM 0 178

NUT - M10 X 1.50

SN: A50001--UP

1шт.

24

MM 0 471

FLAT WASHER - M10

SN: A50001--UP

1шт.

25

EJ 1 518

HOSE

SN: A50001--UP

1шт.

26

CD 8 419

CLAMP, WORM DRIVE

SN: A50001--UP

1шт.

27

E 2 579

NIPPLE

SN: A50001--UP

1шт.

28

F 4 037

FITTING, PIPE

SN: A50001--UP

1шт.

29

SD 5 214

FITTING, PIPE

SN: A50001--UP

1шт.

30

WB 0 466

CONNECTOR

SN: A50001--UP

1шт.
