Запчасти Komatsu WA800-3LC H-A ГИДР. НАСОС. НАСОС ASSEMBLY SAR ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H1610-01A0 )

SN: A50001--UP

-1шт.

|$1

705-32-40350

PUMP ASSEMBLY, (SAR100)

SN: A50001--UP

1шт.

1

705-29-03620

BRACKET

SN: A50001--UP

1шт.

|$3

705-18-03350

BUSHING, PLANE

SN: A50001--UP

2шт.

2

705-17-40010

CASE, GEAR

SN: A50001--UP

1шт.

3

705-18-03240

CARRIER

SN: A50001--UP

1шт.

|$6

705-18-03350

BUSHING, PLANE

SN: A50001--UP

2шт.

4

04020-01228

PIN, DOWEL

SN: A50001--UP

6шт.

5

705-17-03380

O-RING

SN: A50001--UP

2шт.

6

705-29-40760

GEAR, DRIVE

SN: A50001--UP

1шт.

7

705-17-40810

GEAR, DRIVEN

SN: A50001--UP

1шт.

8

705-17-03610

PLATE

SN: A50001--UP

2шт.

9

705-17-03440

RING, BACK-UP

SN: A50001--UP

2шт.

10

705-17-03470

SEAL, RING

SN: A50001--UP

2шт.

11

705-17-03770

BOLT

SN: A50001--UP

4шт.

12

01643-51645

WASHER

SN: A50001--UP

4шт.

13

705-17-03330

COUPLING

SN: A50001--UP

1шт.

14

705-19-03480

O-RING

SN: A50001--UP

1шт.

15

705-19-03470

BOLT

SN: A50001--UP

4шт.

16

705-17-04980

WASHER

SN: A50001--UP

4шт.
