Запчасти Komatsu WA800-3LC E-A КРЕПЛЕНИЯ АККУМУЛЯТОРАING РЕЛЕ И Э/ПРОВОДКА ЭЛЕКТРИКА

Схема запчастей Komatsu WA800-3LC - E-A КРЕПЛЕНИЯ АККУМУЛЯТОРАING РЕЛЕ И Э/ПРОВОДКА ЭЛЕКТРИКА
12
9
4
1
11
10
11
7
3
2
6
14
12
5
13
1
11
10
7
11
8
10

Артикул

Название

Примечание

Количество

1

08088-30000

SWITCH, BATTERY RELAY

SN: A50001--UP

1шт.

2

01435-00830

BOLT

SN: A50001--UP

4шт.

3

427-06-22221

HARNESS, LEFT BATTERY WIRING

SN: A50001--UP

1шт.

|$3

421-09-11160

HOUSING

SN: A50001--UP

1шт.

|$4

421-09-11260

TERMINAL

SN: A50001--UP

1шт.

|$5

08031-20204

TERMINAL

SN: A50001--UP

1шт.

|$6

08034-00414

BAND

SN: A50001--UP

3шт.

|$7

08055-00282

CONNECTOR

SN: A50001--UP

1шт.

4

427-06-A2320

HARNESS, RIGHT BATTERY WIRING

SN: A50009--UP

1шт.

|$29

OR

9

-1шт.

4

427-06-22230

HARNESS, RIGHT BATTERY WIRING

SN: A50001-A50008-UP

1шт.

|$11

421-09-11160

HOUSING

SN: A50001--UP

1шт.

|$12

421-09-11260

TERMINAL

SN: A50001--UP

1шт.

|$13

08031-20204

TERMINAL

SN: A50001--UP

1шт.

|$14

08031-20208

TERMINAL

SN: A50001--UP

1шт.

|$15

08034-00414

BAND

SN: A50001--UP

3шт.

|$16

08055-00381

CONNECTOR

SN: A50001--UP

1шт.

5

427-06-13910

WIRE, BATTERY TO GROUND

SN: A50001--UP

1шт.

6

427-06-13910

WIRE, BATTERY TO GROUND

SN: A50001--UP

1шт.

7

427-06-12352

WIRE, BATTERY TO BATTERY

SN: A50001--UP

2шт.

8

427-06-13921

WIRE, BATTERY TO BATTERY RELAY

SN: A50001--UP

1шт.

9

427-06-12392

WIRE, BATTERY TO BATTERY RELAY

SN: A50001--UP

1шт.

10

424-09-12530

BOOT

SN: A50001--UP

3шт.

|$23

08000-00001

CLAMP, TERMINAL (NEGATIVE)

SN: A50001--UP

4шт.

11

424-09-12540

BOOT

SN: A50001--UP

5шт.

|$25

08000-00000

CLAMP, TERMINAL (POSITIVE)

SN: A50001--UP

4шт.

12

08038-00035

CAP

SN: A50001--UP

4шт.

13

01435-01016

BOLT

SN: A50001--UP

2шт.

14

HARNESS, REAR FRAME WIRING (SEE FIG. E0202-01A0 )

SN: A50001--UP

-1шт.

Выбрано товаров: 29
