Запчасти Komatsu WA800-3E0 ТАБЛИЧКИ (№7-) ТАБЛИЧКИ, ТУРЦИЯ-АНГЛ.

1

427-93-22661

Plate, Transmission Oil Level

SN: 70030-UP

1шт.

2

427-93-22590

Plate, Fuel Cut Off

SN: 70030-UP

1шт.

3

427-93-22421

Lubrication Chart

SN: 70030-UP

1шт.

4

427-93-21890

Plate, Name

SN: 70030-UP

1шт.

5

427-93-21850

Plate, Line

SN: 70030-UP

2шт.

6

09659-A057B

Plate, Warning, Explosion Hazard

SN: 70030-UP

5шт.

7

427-93-22430

Plate, Greasing, Lubrication

SN: 70030-UP

1шт.

8

427-93-22460

Plate, Greasing, Lubrication

SN: 70030-UP

1шт.

9

426-93-41620

Plate, Symbol, Fuel Filler

SN: 70030-UP

1шт.

10

427-93-22620

Plate, Auto-greasing

SN: 70030-UP

1шт.

11

427-93-22610

Plate, Auto-greasing

SN: 70030-UP

1шт.

12

09690-C0710

Plate, Komatsu Logo

SN: 70030-UP

1шт.

13

09601-00003

Plate, Name (Limited Supply)

SN: 70030-UP

1шт.

14

04418-13060

Screw

SN: 70030-UP

4шт.

15

09637-A0880

Plate, Service Instruction, Air Cleaner

SN: 70030-UP

1шт.

16

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 70030-UP

4шт.

17

09806-C1683

Plate, Danger, Keep Away from Machine

SN: 70030-UP

2шт.

18

09807-C1683

Plate, Danger, Keep Out under Work Equipment

SN: 70030-UP

2шт.

19

09811-C088B

Decal, Warning, Brake Oil

SN: 70030-UP

1шт.

20

427-93-21880

Plate, Name

SN: 70030-UP

1шт.

21

427-93-22470

Plate, Warning

SN: 70030-UP

2шт.

22

427-93-22520

Plate, Relay

SN: 70030-UP

1шт.

23

09669-0000A

Plate, Symbol, Coolant Filler

SN: 70030-UP

1шт.

24

09664-62F11

Plate, Danger, Battery

SN: 70030-UP

4шт.

25

209-00-71940

Plate, Stairway Lamp

SN: 70030-UP

1шт.

26

09963-A1640

Tag, Danger, Do Not Operate

SN: 70030-UP

1шт.

27

426-93-21570

Plate Assembly

SN: 70030-UP

1шт.

28

427-93-22540

Plate, Brake Oil Level

SN: 70030-UP

1шт.

29

427-S05-7110

Plate, Add. Cooler Grease

SN: 70030-UP

1шт.

30

427-S05-7120

Plate, Add. Cooler Grease

SN: 70030-UP

1шт.
