Запчасти Komatsu WA800-3E0 ТАБЛИЧКИ (№7-) ТАБЛИЧКИ, ИСПАНИЯ, TEXT ТИП

1

09667-01001

Plate, Caution, Rotating Object

SN: 70030-UP

2шт.

2

42C-V00-1151

Plate, Transmission Oil Level

SN: 70030-UP

1шт.

3

428-V00-1170

Plate, Fuel Cut Off

SN: 70030-UP

1шт.

4

427-V00-2420

Oil Chart, Spanish

SN: 70030-UP

1шт.

5

427-93-21890

Plate, Name

SN: 70030-UP

1шт.

6

427-93-21850

Plate, Line

SN: 70030-UP

2шт.

7

09659-51000

Plate, Warning, Explosion Hazard

SN: 70030-UP

5шт.

8

426-V00-1150

Plate, Caution

SN: 70030-UP

1шт.

9

427-V00-2320

Plate, Greasing, Lubrication

SN: 70030-UP

1шт.

10

09690-C0710

Plate, Komatsu Logo

SN: 70030-UP

1шт.

11

09601-10001

Plate, Name (Limited Supply)

SN: 70030-UP

1шт.

|$11

04418-13060

Screw

SN: 70030-UP

4шт.

12

428-V00-2190

Plate, Air Cleaner

SN: 70030-UP

1шт.

13

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 70030-UP

4шт.

14

09812-01000

Plate, Danger, Keep a Safe Distance

SN: 70030-UP

2шт.

15

09807-C1683

Plate, Danger, Keep Out under Work Equipment

SN: 70030-UP

2шт.

16

09811-01000

Plate, Warning, Brake Oil

SN: 70030-UP

1шт.

17

427-93-21880

Plate, Name

SN: 70030-UP

1шт.

18

428-V00-2170

Plate, Warning

SN: 70030-UP

2шт.

19

428-V00-2140

Plate, Relay

SN: 70030-UP

1шт.

20

09669-0000A

Plate, Symbol, Coolant Filler

SN: 70030-UP

1шт.

21

209-00-71940

Plate, Stairway Lamp, Step Light Switch

SN: 70030-UP

1шт.

22

09963-01001

Tag, Danger, Do Not Operate

SN: 70030-UP

1шт.

23

421-V00-2111

Plate Assembly

SN: 70030-UP

1шт.

24

427-V00-2330

Plate, Emergency Ladder, Emergency Ladder

SN: 70030-UP

1шт.

25

427-V00-2340

Plate, Brake Oil Level

SN: 70030-UP

1шт.

26

427-S05-6860

Plate, Add. Cooler Grease

SN: 70041-UP

1шт.

27

427-S05-6870

Plate, Add. Cooler Grease

SN: 70041-UP

1шт.
