Запчасти Komatsu WA800-3 МАРКИРОВКА (JAPAN) (ЭЛЕКТР. GOVENOR PEC.) МАРКИРОВКА

1

09667-A0880

PLATE¤ SAFETY,FAN

SN: 50001-50008

2шт.

2

362-54-17230

PLATE¤ CAUTION,HOSE CHANGE

SN: 50001-UP

1шт.

3

419-93-11890

PLATE¤ CAUTION,TRANSMISSION OIL TEMPERATURE

SN: 50001-50008

1шт.

4

421-93-11350

PLATE¤ INSTRUCTION,ENGINE OIL DRAIN

SN: 50001-UP

1шт.

5

421-93-11810

PLATE¤ INSTRUCTION,RADIATOR WATER DRAIN

SN: 50001-UP

2шт.

6

424-93-11320

PLATE¤ CAUTION,STARTING AND INSPECTION

SN: 50001-50008

1шт.

7

427-93-21390

PLATE¤ CAUTION,TRANSMISSION OIL LEVEL

SN: 50001-UP

1шт.

8

427-93-21410

PLATE¤ CAUTION,TRANSMISSION OIL LEVEL

SN: 50001-UP

1шт.

9

428-93-11370

PLATE,FUEL CUT

SN: 50001-UP

1шт.

10

427-93-21470

CHART¤ OIL

SN: 50001-UP

1шт.

11

427-93-11240

PLATE¤ MARK,WA800

SN: 50001-UP

2шт.

12

417-93-21220

PLATE¤ MARK,AVANCE

SN: 50001-UP

2шт.

13

09659-A057A

PLATE¤ SAFETY,ACCUMULATOR

SN: 50009-UP

5шт.

|13

417-93-21210

PLATE¤ CAUTION,ACCUMULATOR

SN: 50001-50008

5шт.

14

426-93-11320

PLATE¤ CAUTION,INSTALL THE BUCKET

SN: 50001-UP

1шт.

15

427-93-11171

PLATE¤ OPERATING,REMOTE GREASE¤ FRONT

SN: 50001-UP

1шт.

16

427-93-11181

PLATE¤ OPERATING,REMOTE GREASE¤ REAR

SN: 50001-UP

1шт.

17

09690-C0710

PLATE¤ MARK,KOMATSU

SN: 50001-UP

1шт.

18

09601-10000

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 50010-UP

1шт.

|18

09601-10010

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 50001-50009

1шт.

19

04418-13060

SCREW

SN: 50001-UP

4шт.

20

427-93-21380

PLATE¤ CAUTION,AIR CLEANER

SN: 50001-UP

1шт.

21

09960-01001

PLATE¤ MARK

SN: 50001-UP

4шт.

22

09806-C1682

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 50009-UP

2шт.

|22

09806-C1680

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 50001-50008

2шт.

23

09807-C1682

PLATE¤ SAFETY,KEEP OUT

SN: 50009-UP

2шт.

|23

09807-C1680

PLATE¤ SAFETY,KEEP OUT

SN: 50001-50008

2шт.

24

09811-00100

PLATE¤ CAUTION,BRAKE OIL

SN: 50001-UP

1шт.

25

427-93-21710

PLATE¤ MARK,FUSE

SN: 50019-UP

2шт.

|25

427-93-21130

PLATE¤ MARK,FUSE

SN: 50001-50018

2шт.

26

427-93-21121

PLATE¤ WARNING,BATTERY BOX

SN: 50001-UP

1шт.

27

427-93-21141

PLATE¤ INSTRUCTION,BRAKE OIL LEVEL

SN: 50001-UP

1шт.

28

427-93-21151

PLATE¤ INSTRUCTION,BRAKE OIL LEVEL

SN: 50001-UP

1шт.

29

427-93-21160

PLATE,BRAKE OIL DRAIN

SN: 50001-UP

1шт.

30

427-93-21170

PLATE¤ NAME

SN: 50001-UP

1шт.

31

561-93-61481

PLATE¤ SAFETY,EMERGENCY STOP

SN: 50001-UP

1шт.
