Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TORQUE CONVERTER SERIAL NO.
-1шт.
|$1
427-15-01001
TORQFLOW ASS'Y
SN: (1045)-(1100)
1шт.
|$2
0
TORQFLOW ASS'Y
SN: 10001-(1044)
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2524.
-1шт.
|$$5
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
427-15-00013
TRANSMISSION ASS'Y
SN: (1144)-UP
1шт.
|$6
0
TRANSMISSION ASS'Y
SN: (1101)-(1143)
1шт.
|$7
427-15-00011
TRANSMISSION ASS'Y
SN: 10001-(1100)
1шт.
|$$9
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2524.
-1шт.
|$9
427-15-00201
CONTROL VALVE A.
SN: (1101)-UP
1шт.
|$10
427-15-00200
CONTROL VALVE A.
SN: 10001-(1100)
1шт.
|$$12
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2521 TO 2524.
-1шт.
|$12
427-15-00300
VALVE ASS'Y
SN: 10001-UP
1шт.
|$$14
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2521 TO 2523.
-1шт.
1
195-15-35210
BODY,VALVE
SN: 10001-UP
1шт.
3
07042-20211
PLUG
SN: 10001-UP
1шт.
4
195-15-35280
STOPPER
SN: 10001-UP
2шт.
6
195-15-35240
VALVE
SN: 10001-UP
2шт.
10
566-15-45580
SPRING,(L=68.7)
SN: 10001-UP
1шт.
13
195-15-35230
VALVE
SN: 10001-UP
1шт.
14
237-14-12940
SPRING,(L=35)
SN: 10001-UP
1шт.
18
195-15-34160
SPRING,(L=74.5)
SN: 10001-UP
1шт.
19
427-15-15310
VALVE
SN: (1144)-UP
1шт.
19
195-15-34130
VALVE
SN: 10001-(1143)
1шт.
20
195-15-36210
SPRING,(L=86)
SN: 10001-UP
1шт.
21
195-15-35521
VALVE
SN: 10001-UP
1шт.
22
560-43-14330
SHIM, 0.5MM (K4)
SN: (1310)-UP
5шт.
22
560-43-14330
SHIM, 0.5MM (K4)
SN: 10001-(1309)
4шт.
24
195-15-36170
SPRING,(L=80)
SN: 10001-UP
1шт.
25
195-15-36160
SPRING,(L=100)
SN: 10001-UP
1шт.
27
195-15-35560
PISTON
SN: 10001-UP
1шт.
28
195-15-35851
COVER
SN: 10001-UP
1шт.
32
287-15-15380
VALVE
SN: 10001-UP
1шт.
34
195-15-35530
VALVE
SN: 10001-UP
1шт.
35
195-15-35830
PLATE
SN: 10001-UP
1шт.
37
427-15-15631
VALVE
SN: 10001-UP
1шт.
38
125-15-11230
PLUG
SN: 10001-UP
1шт.
39
195-15-35860
BOSS
SN: 10001-UP
1шт.
42
195-15-35870
PLATE
SN: 10001-UP
1шт.
43
195-15-35291
STOPPER
SN: 10001-UP
1шт.
45
195-15-35810
PLATE
SN: 10001-UP
2шт.
Выбрано товаров: 67
