Запчасти Komatsu WA800-1 ТРАНСМИССИЯ (ПЕРЕД. МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TORQUE CONVERTER SERIAL NO.

-1шт.

|$1

427-15-01001

TORQFLOW ASS'Y

SN: (1045)-(1100)

1шт.

|$2

0

TORQFLOW ASS'Y

SN: 10001-(1044)

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2301 TO 2524.

-1шт.

|$$5

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$5

427-15-00013

TRANSMISSION ASS'Y

SN: (1144)-UP

1шт.

|$6

0

TRANSMISSION ASS'Y

SN: (1101)-(1143)

1шт.

|$7

427-15-00011

TRANSMISSION ASS'Y

SN: 10001-(1100)

1шт.

|$$9

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.2501 TO 2524.

-1шт.

|$9

427-15-00130

CARRIER ASS'Y

SN: 10001-UP

1шт.

1

0

CARRIER

SN: 10001-UP

1шт.

2

568-15-11380

PLUG

SN: 10001-UP

8шт.

3

427-15-12420

GEAR

SN: 10001-UP

8шт.

4

582-15-19720

BEARING

SN: 10001-UP

16шт.

5

427-15-12560

WASHER,THRUST

SN: 10001-UP

16шт.

6

427-15-12520

SHAFT

SN: 10001-UP

4шт.

7

04260-00635

BALL

SN: 10001-UP

4шт.

8

427-15-12370

COVER

SN: 10001-UP

1шт.

9

01252-31035

BOLT

SN: 10001-UP

4шт.

10

427-15-12651

GEAR,RING

SN: (1062)-UP

1шт.

10

0

GEAR,RING

SN: 10001-(1061)

1шт.

11

198-15-29520

RING

SN: 10001-UP

1шт.

12

427-15-12360

COVER

SN: 10001-UP

1шт.

13

01252-31035

BOLT

SN: 10001-UP

4шт.

14

427-15-12630

GEAR,RING

SN: 10001-UP

1шт.

15

427-15-11161

HOUSING

SN: (1062)-UP

1шт.

15

0

HOUSING

SN: 10001-(1061)

1шт.

16

04020-01842

PIN,DOWEL

SN: 10001-UP

2шт.

17

427-15-11170

HOUSING,FORWARD

SN: 10001-UP

1шт.

18

568-15-11370

PIN,(D=20, L=237.5)

SN: 10001-UP

6шт.

19

427-15-12760

PISTON,FORWARD

SN: 10001-UP

1шт.

20

427-15-19210

RING,SEAL (K3)

SN: 10001-UP

1шт.

21

195-15-29210

RING,SEAL (K3)

SN: 10001-UP

1шт.

22

427-15-12640

GEAR,RING

SN: 10001-UP

1шт.

23

198-15-22710

DISC

SN: 10001-UP

6шт.

24

198-15-22720

PLATE

SN: 10001-UP

5шт.

25

568-15-12960

SPRING,(L=108.5)

SN: 10001-UP

12шт.

26

195-15-12880

SPRING

SN: 10001-UP

36шт.
