Запчасти Komatsu WA80-3 КАБИНА (ДВЕРЬ ЭЛЕМЕНТЫ КРЕПЛЕНИЯ¤ ЛЕВ.)(№-) OPERATIORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$13

415-56-22094

CAB ASS'Y

SN: 13275-UP

1шт.

|$14

0

CAB ASS'Y

SN: 13071-13274

1шт.

|$15

415-56-22092

CAB ASS'Y

SN: 12268-13070

1шт.

|$16

415-56-22091

CAB ASS'Y

SN: 12238-12267

1шт.

|$17

415-56-22090

CAB ASS'Y

SN: 12001-12237

1шт.

|$18

416-56-21030

CAB ASS'Y

SN: 11001-12000

1шт.

|$19

415-56-22424

CAB ASS'Y,(WITH RADIO)

SN: 13275-UP

1шт.

|$20

0

CAB ASS'Y,(WITH RADIO)

SN: 13071-13274

1шт.

|$21

415-56-22422

CAB ASS'Y,(WITH RADIO)

SN: 12268-13070

1шт.

|$22

415-56-22421

CAB ASS'Y,(WITH RADIO)

SN: 12238-12267

1шт.

|$23

415-56-22420

CAB ASS'Y,(WITH RADIO)

SN: 12001-12237

1шт.

|$24

416-56-21040

CAB ASS'Y,(WITH RADIO)

SN: 11001-12000

1шт.

|$25

415-954-2214

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 13275-UP

1шт.

|$26

0

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 13071-13274

1шт.

|$27

415-954-2212

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 12268-13070

1шт.

|$28

415-954-2211

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 12238-12267

1шт.

|$29

415-954-2210

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 12001-12237

1шт.

|$30

416-954-2010

CAB ASS'Y,(HEAT WIRE GLASS)

SN: 11001-12000

1шт.

|$31

416-954-2020

CAB ASS'Y,(HEAT WIRE GLASS + RADIO)

SN: 11001-12000

1шт.

|$32

415-56-22414

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 13275-UP

1шт.

|$33

0

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 13071-13274

1шт.

|$34

415-56-22412

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12268-13070

1шт.

|$35

415-56-22411

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12238-12267

1шт.

|$36

415-56-22410

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12001-12237

1шт.

|$37

415-56-21410

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 11001-12000

1шт.

|$38

415-56-22434

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 13275-UP

1шт.

|$39

0

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 13071-13274

1шт.

|$40

415-56-22432

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12268-13070

1шт.

|$41

415-56-22431

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12238-12267

1шт.

|$42

415-56-22430

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12001-12237

1шт.

|$43

415-56-21420

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 11001-12000

1шт.

|$44

415-954-2050

CAB ASS'Y,(HEAT WIRE GLASS + AIR-CON)

SN: 11001-12000

1шт.

|$45

415-954-2060

CAB ASS'Y,(H/W/GLASS + AIR-CON + RADIO)

SN: 11001-12000

1шт.

|$$34

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-18B1.

-1шт.

|$47

417-56-21400

DOOR ASS'Y,L.H.

SN: 11001-UP

1шт.

|$$36

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-11B0 TO K0210-13B0.

-1шт.

1

417-56-21430

CATCH

SN: 11001-UP

1шт.

2

01023-60520

SCREW

SN: 11001-UP

3шт.

3

08037-05016

GROMMET

SN: 11001-UP

1шт.

4

417-56-21590

GRIP

SN: 11001-UP

1шт.

5

01435-01025

BOLT

SN: 11001-UP

2шт.

6

363-54-31450

CAP

SN: 11001-UP

2шт.

7

417-56-21220

COVER,L.H.

SN: 11001-UP

1шт.

7

419-54-16730

CLIP,TRIM

SN: 11001-UP

9шт.

8

417-56-21710

HINGE

SN: 11001-UP

2шт.

9

01010-80825

BOLT

SN: 11001-UP

4шт.

10

01643-30823

WASHER

SN: 11001-UP

4шт.

11

417-56-21260

PLATE

SN: 11001-UP

1шт.

12

417-56-21270

WASHER,WAVE

SN: 11001-UP

2шт.

13

427-W93-1770

WASHER

SN: 11001-UP

1шт.

14

01435-00612

BOLT

SN: 11001-UP

1шт.

15

417-56-21370

SHEET

SN: 11001-UP

1шт.

|$$53

SERVICE PARTS

-1шт.

16

417-56-21720

HINGE

SN: 11001-UP

2шт.
