Запчасти Komatsu WA80-3 КАБИНА (ДВЕРЬ) (С КОНДИЦИОНЕРОМ)(№-) OPERATIORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$7

415-56-22414

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 13275-UP

1шт.

|$8

0

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 13071-13274

1шт.

|$9

415-56-22412

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12268-13070

1шт.

|$10

415-56-22411

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12238-12267

1шт.

|$11

415-56-22410

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 12001-12237

1шт.

|$12

415-56-21410

CAB ASS'Y,(WITH AIR CONDITIONER)

SN: 11001-12000

1шт.

|$13

415-56-22434

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 13275-UP

1шт.

|$14

0

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 13071-13274

1шт.

|$15

415-56-22432

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12268-13070

1шт.

|$16

415-56-22431

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12238-12267

1шт.

|$17

415-56-22430

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 12001-12237

1шт.

|$18

415-56-21420

CAB ASS'Y,(AIR CONDITIONER + RADIO)

SN: 11001-12000

1шт.

|$19

415-954-2050

CAB ASS'Y,(HEAT WIRE GLASS + AIR-CON)

SN: 11001-12000

1шт.

|$20

415-954-2060

CAB ASS'Y,(H/W/GLASS + AIR-CON + RADIO)

SN: 11001-12000

1шт.

|$21

415-56-21503

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 13275-UP

1шт.

|$22

0

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 13071-13274

1шт.

|$23

415-56-21501

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 12268-13070

1шт.

|$24

415-56-21500

CAB ASS'Y,(FOR SNOW BLADE + RADIO + A/C)

SN: 12001-12267

1шт.

|$$19

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01B0 TO K0210-18B1.

-1шт.

1

01220-40810

SCREW

SN: 11001-UP

4шт.

2

09415-01008

CAP,(WITHOUT BEACON LAMP)

SN: 11001-UP

1шт.

3

423-56-21960

STRIKER

SN: 11001-UP

2шт.

4

01240-00820

SCREW

SN: 11001-UP

4шт.

5

421-54-15760

WASHER

SN: 11001-UP

4шт.

6

419-54-15690

PLATE

SN: 11001-UP

4шт.

7

01010-80825

BOLT

SN: 11001-UP

12шт.

8

01643-30823

WASHER

SN: 11001-UP

12шт.

9

421-54-15730

SEAL,DOOR

SN: 11001-UP

2шт.

10

417-926-2261

BRACKET,L.H.

SN: 11001-UP

1шт.

11

01643-31232

WASHER

SN: 11001-UP

2шт.

12

01435-01030

BOLT

SN: 11001-UP

4шт.

13

07005-01412

SEAL, WASHER

SN: 11001-UP

4шт.

14

42A-925-1530

CATCH,L.H.

SN: 11001-UP

1шт.

15

417-926-2280

STOPPER,L.H.

SN: 11001-UP

1шт.

16

01023-70430

SCREW,L.H.

SN: 11001-UP

1шт.

17

416-64-15620

WASHER,L.H.

SN: 11001-UP

1шт.
