Запчасти Komatsu WA700-3L FIG. T-A V-ОБРАЗН КОВШ, 8.7M - ЗУБЬЯ- С ЗАЩИТОЙ ШИН РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

428-70-A2300

BUCKET ASSEMBLY WITH TEETH

SN: A50001 --UP

1шт.

1

NSS

BUCKET

SN: A50001 --UP

1шт.

2

PC0797

LIP ASSEMBLY, LOADMASTER

SN: A50001 --UP

1шт.

3

PC0786

ADAPTER, STADDLE LEG CORNER

SN: A50001 --UP

2шт.

4

PC0787

SHROUD, WING

SN: A50001 --UP

2шт.

5

PC0790

SHROUD, LIP, RIGHT HAND

SN: A50001 --UP

3шт.

6

PC0796

CAP, WEAR

SN: A50001 --UP

8шт.

7

PC0788

ADAPTER (WELDED)

SN: A50001 --UP

2шт.

8

PC0791

PIN (FOR SHROUD)

SN: A50001 --UP

9шт.

9

PC0795

ADAPTER (WELDED)

SN: A50001 --UP

2шт.

10

PC0794

ADAPTER (WELDED)

SN: A50001 --UP

2шт.

11

PB9835

PIN ASSEMBLY (FOR TEETH)

SN: A50001 --UP

8шт.

12

PC0789

SHROUD, LIP, LEFT HAND

SN: A50001 --UP

3шт.

13

PC0793

SHROUD, LIP, CENTER

SN: A50001 --UP

1шт.

14

PC0792

V POINT, SUPER V

SN: A50001 --UP

8шт.

15

428-70-A2360

PLATE, LEFT HAND (WELDED)

SN: A50001 --UP

1шт.

16

428-70-A2370

PLATE, RIGHT HAND (WELDED)

SN: A50001 --UP

1шт.

17

428-70-A2120

PLATE (WELDED)

SN: A50001 --UP

2шт.

18

428-70-A2340

PLATE (WELDED)

SN: A50001 --UP

2шт.

19

428-70-12250

PLATE (WELDED)

SN: A50001 --UP

2шт.

20

428-70-A2230

PLATE, LEFT HAND (WELDED)

SN: A50001 --UP

1шт.

21

428-70-A2240

PLATE, RIGHT HAND (WELDED)

SN: A50001 --UP

1шт.

22

428-70-12211

WING, DEFLECTION

SN: A50001 --UP

2шт.

23

428-70-A2210

PLATE, SIDE, LEFT HAND

SN: A50001 --UP

1шт.

24

428-70-A2220

PLATE, SIDE, RIGHT HAND

SN: A50001 --UP

1шт.
