Запчасти Komatsu WA700-3 КОНДИЦ. ВОЗДУХА (БЛОК КОНДИЦИОНЕРА¤ /)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

425-07-21111

AIR CONDITIONER U.,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0710-05A0 AND K0710-06A0.

-1шт.

1

ND245420-4200

CASE ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

2

ND245420-0210

CASE ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

3

ND116452-0561

CASE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

4

ND447600-0651

EVAPORATOR,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

|4

ND949142-0030

O-RING,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

5

ND116410-9680

UNIT ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

6

ND447500-1030

VALVE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

7

ND113600-9260

VALVE ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

8

ND146622-6880

PACKING,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

9

ND116730-0530

DAMPER ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

10

ND116730-0520

DAMPER ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

11

ND017732-3041

LEVER,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

12

ND017732-3050

LEVER,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

13

ND017732-3060

LEVER,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

14

ND116662-0581

SHAFT,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

15

ND116662-0590

SHAFT,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

16

ND116427-5540

PIPE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

17

ND116427-2320

PIPE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

18

ND017660-3490

BRACKET,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

19

ND446870-2320

TUBE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

|19

ND949142-0010

O-RING,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

|19

ND949142-0030

O-RING,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

20

ND146984-4750

GROMMET,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

21

ND246440-5200

WIRING HARNESS,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

22

ND949046-2150

BOLT,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

23

ND077500-3620

THERMOSTAT,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

24

ND063700-6580

SERVO MOTOR ASS'Y,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

25

ND705220-0500

HOSE,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

26

ND146625-2630

BUSHING,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

27

ND246690-2930

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

28

ND146625-5040

BUSHING,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

29

ND246690-2840

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

30

ND017231-1400

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

31

ND246690-6740

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

32

ND246690-5150

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

33

ND949351-0720

CLAMP,SEE FIG. K4010-15A0

SN: 50001-51000

6шт.

34

ND949001-1730

SCREW,SEE FIG. K4010-15A0

SN: 50001-51000

11шт.

35

ND949008-0780

SCREW,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

36

ND913700-3081

SCREW,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

37

ND909300-5121

SCREW,SEE FIG. K4010-15A0

SN: 50001-51000

3шт.

38

ND909300-6141

SCREW,SEE FIG. K4010-15A0

SN: 50001-51000

12шт.

39

ND017773-0180

CLIP,SEE FIG. K4010-15A0

SN: 50001-51000

2шт.

40

ND017773-0140

CLIP,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

41

ND146642-7930

PLATE,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

42

ND700904-0050

SHEET,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.

43

ND700901-0050

SHEET,SEE FIG. K4010-15A0

SN: 50001-51000

1шт.
