Запчасти Komatsu WA700-3 УПРАВЛ-Е ДВИГАТЕЛЕМ (АКСЕЛЕРАТОР ПЕДАЛЬ)(№-7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$1

42C-43-11410

PEDAL ASS'Y,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

1

417-43-11210

PEDAL,SEE FIG. K4010-51A0

SN: 50001-UP

1шт.

2

417-43-11330

CLIP,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

3

421-43-21710

PIN,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

4

421-43-21720

PIN,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

5

421-43-21730

BEARING,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

6

421-43-21740

BOLT,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

7

421-43-21750

PIN,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

8

421-43-21760

ROLLER,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

9

421-43-21770

BELLOWS,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

10

421-43-21780

COVER,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

11

421-43-21790

PLATE,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

12

421-43-21810

BODY ASS'Y,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

13

42C-43-11820

PUSH ROD ASS'Y,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

14

421-43-21830

CASE,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

15

421-43-21840

GUIDE,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

16

421-43-21850

SPRING,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

17

421-43-21860

GUIDE,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

18

421-43-21870

GEAR,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

19

421-43-21880

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

20

421-43-21890

BRACKET ASS'Y,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

21

421-43-21910

POTENTIOMETER,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

22

421-43-21920

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

23

421-43-21930

RING,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

24

01010-80612

BOLT,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

25

01220-40310

SCREW,SEE FIG. K4010-51A0

SN: 51001-UP

5шт.

26

01220-40408

SCREW,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

27

01220-40416

SCREW,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

28

01220-40510

SCREW,SEE FIG. K4010-51A0

SN: 51001-UP

4шт.

29

01580-10605

NUT,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

30

01580-10806

NUT,SEE FIG. K4010-51A0

SN: 50001-UP

1шт.

31

01601-20307

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

3шт.

32

01601-20410

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

2шт.

33

01641-20305

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

3шт.

34

01641-20405

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

4шт.

35

01641-20508

WASHER,SEE FIG. K4010-51A0

SN: 51001-UP

4шт.

36

08192-13810

CONNECTOR,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

37

08192-13910

CONNECTOR,SEE FIG. K4010-51A0

SN: 51001-UP

1шт.

38

01435-00625

BOLT,SEE FIG. K4010-51A0

SN: 51001-UP

3шт.
