Запчасти Komatsu WA700-3 ЧАСТИ КАБИНЫ(СПЕЦ-Я TBG)(№-7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$9

427-56-21010

CAB ASS'Y,(TBG SPEC.)

SN: 51001-UP

1шт.

|$10

426-56-21053

CAB ASS'Y,(TBG SPEC.)

SN: 50036-51000

1шт.

|$11

426-56-21052

CAB ASS'Y,(TBG SPEC.)

SN: 50008-50035

1шт.

|$12

426-56-21051

CAB ASS'Y,(TBG SPEC.)

SN: 50001-50007

1шт.

|$13

427-56-21020

CAB ASS'Y,(AM/FM RADIO) (TBG SPEC.)

SN: 51001-UP

1шт.

|$14

426-56-21402

CAB ASS'Y,(AM/FM RADIO) (TBG SPEC.)

SN: 50036-51000

1шт.

|$15

426-56-21401

CAB ASS'Y,(AM/FM RADIO) (TBG SPEC.)

SN: 50011-50035

1шт.

|$16

426-56-21400

CAB ASS'Y,(AM/FM RADIO) (TBG SPEC.)

SN: 50001-50010

1шт.

|$17

427-56-21030

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 51001-UP

1шт.

|$18

428-U94-2121

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 50036-51000

1шт.

|$19

428-U94-2120

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 50001-50035

1шт.

|$20

427-56-21050

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 51001-UP

1шт.

|$21

428-56-21181

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 50036-51000

1шт.

|$22

428-56-21180

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 50001-50035

1шт.

|$23

428-U94-2311

CAB ASS'Y,(W/LOAD METER,RADIO) (TBG)

SN: 50036-UP

1шт.

|$24

428-U94-2310

CAB ASS'Y,(W/LOAD METER,RADIO) (TBG)

SN: 50001-50035

1шт.

|$$17

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A1 TO K0210-20A1.

-1шт.

1

421-56-21561

COVER,L.H.

SN: 50001-UP

1шт.

2

421-56-21571

COVER,R.H.

SN: 50001-UP

1шт.

3

426-56-21391

BRACKET

SN: 50001-UP

1шт.

4

417-54-21380

SEAL

SN: 50001-UP

2шт.

5

426-56-21321

SEAL

SN: 50001-UP

1шт.

6

426-56-21680

SHEET,L.H.

SN: 50001-UP

1шт.

7

426-56-21690

SHEET,R.H.

SN: 50001-UP

1шт.

8

421-09-21410

SCREW

SN: 50001-UP

6шт.

9

421-09-21430

SCREW

SN: 50001-UP

4шт.

10

01642-40810

WASHER

SN: 50001-UP

10шт.

11

421-09-21410

SCREW

SN: 50001-UP

2шт.

12

20G-54-13420

ASHTRAY

SN: 50001-UP

1шт.
