Запчасти Komatsu WA700-3 КАБИНА (КРЫШКА И ЧАСТИ ДВЕРИ)(№-7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$14

428-56-21100

CAB ASS'Y

SN: 54001-UP

1шт.

|$15

425-56-21910

CAB ASS'Y

SN: 51001-54000

1шт.

|$16

425-56-21951

CAB ASS'Y,(EXCEPT JAPAN)

SN: 51001-UP

1шт.

|$17

427-56-21010

CAB ASS'Y,(TBG SPEC.)

SN: 51001-UP

1шт.

|$18

425-56-21961

CAB ASS'Y,(AM/FM RADIO) (EXCEPT JAPAN)

SN: 51001-UP

1шт.

|$19

427-56-21020

CAB ASS'Y,(AM/FM RADIO) (TBG SPEC.)

SN: 51001-UP

1шт.

|$20

428-56-21050

CAB ASS'Y,(WITH LAMINATED GLASS)

SN: 51001-UP

1шт.

|$21

425-U94-2410

CAB ASS'Y,(WITH LOAD METER)

SN: 51001-UP

1шт.

|$22

428-56-21030

CAB ASS'Y,(/LOAD METER) (EXCEPT JAPAN)

SN: 51001-UP

1шт.

|$23

427-56-21030

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 51001-UP

1шт.

|$24

428-56-21020

CAB ASS'Y,(WITH CURTAIN) (EXCEPT JAPAN)

SN: 51001-UP

1шт.

|$25

427-56-21050

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 51001-UP

1шт.

|$26

428-56-21500

CAB ASS'Y

SN: 51001-UP

1шт.

|$27

428-56-21600

CAB ASS'Y

SN: 51001-UP

1шт.

|$$15

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-20A1.

-1шт.

1

01220-40810

SCREW

SN: 50001-UP

4шт.

2

09415-01008

CAP

SN: 50001-UP

3шт.

3

423-56-21960

STRIKER

SN: 50001-UP

2шт.

4

01240-00825

SCREW

SN: 50001-UP

4шт.

5

421-54-15760

WASHER

SN: 50001-UP

4шт.

6

419-54-15690

PLATE

SN: 50001-UP

4шт.

7

01010-80825

BOLT

SN: 50001-UP

12шт.

8

01643-30823

WASHER

SN: 50001-UP

12шт.

9

423-56-21710

CUSHION

SN: 50001-UP

2шт.

10

421-56-11350

SEAL,DOOR

SN: 50001-UP

2шт.

11

425-56-21880

COVER

SN: 51001-UP

2шт.

12

421-09-21460

SCREW

SN: 51001-UP

4шт.

13

08037-01008

GROMMET

SN: 50001-UP

2шт.

14

426-56-21990

PLUG

SN: 50001-UP

2шт.
