Запчасти Komatsu WA700-3 КАБИНА (КРЫШКА И ЧАСТИ ДВЕРИ)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$13

426-56-21024

CAB ASS'Y

SN: 50036-51000

1шт.

|$14

426-56-21023

CAB ASS'Y

SN: 50001-50035

1шт.

|$15

426-56-21053

CAB ASS'Y,(TBG SPEC.)

SN: 50036-51000

1шт.

|$16

426-56-21052

CAB ASS'Y,(TBG SPEC.)

SN: 50008-50035

1шт.

|$17

426-56-21051

CAB ASS'Y,(TBG SPEC.)

SN: 50001-50007

1шт.

|$18

426-56-21402

CAB ASS'Y,(TBG SPEC.) (AM/FM)

SN: 50036-51000

1шт.

|$19

426-56-21401

CAB ASS'Y,(TBG SPEC.) (AM/FM)

SN: 50011-50035

1шт.

|$20

426-56-21400

CAB ASS'Y,(TBG SPEC.) (AM/FM)

SN: 50001-50010

1шт.

|$21

426-56-21032

CAB ASS'Y,(EXCEPT JAPAN)

SN: 50036-51000

1шт.

|$22

426-56-21031

CAB ASS'Y,(EXCEPT JAPAN)

SN: 50001-50035

1шт.

|$23

426-56-21301

CAB ASS'Y,(EXCEPT JAPAN) (AM/FM)

SN: 50036-51000

1шт.

|$24

426-56-21300

CAB ASS'Y,(EXCEPT JAPAN) (AM/FM)

SN: 50001-50035

1шт.

|$25

426-56-21081

CAB ASS'Y,(WITH HEAT ABSORBING GLASS)

SN: 50036-51000

1шт.

|$26

426-56-21080

CAB ASS'Y,(WITH HEAT ABSORBING GLASS)

SN: 50001-50035

1шт.

|$27

428-U94-2171

CAB ASS'Y,(WITH LOAD METER)

SN: 50036-51000

1шт.

|$28

428-U94-2170

CAB ASS'Y,(WITH LOAD METER)

SN: 50001-50035

1шт.

|$29

428-U94-2121

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 50036-51000

1шт.

|$30

428-U94-2120

CAB ASS'Y,(WITH LOAD METER) (TBG SPEC.)

SN: 50001-50035

1шт.

|$31

428-U94-2181

CAB ASS'Y,(/LOAD METER) (EXCEPT JAPAN)

SN: 50036-51000

1шт.

|$32

428-U94-2180

CAB ASS'Y,(/LOAD METER) (EXCEPT JAPAN)

SN: 50001-50035

1шт.

|$33

426-56-21581

CAB ASS'Y,(WITH CURTAIN)

SN: 50036-51000

1шт.

|$34

426-56-21580

CAB ASS'Y,(WITH CURTAIN)

SN: 50001-50035

1шт.

|$35

428-56-21181

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 50036-51000

1шт.

|$36

428-56-21180

CAB ASS'Y,(WITH CURTAIN) (TBG SPEC.)

SN: 50001-50035

1шт.

|$37

428-56-21171

CAB ASS'Y,(WITH CURTAIN) (EXCEPT JAPAN)

SN: 50036-51000

1шт.

|$38

428-56-21170

CAB ASS'Y,(WITH CURTAIN) (EXCEPT JAPAN)

SN: 50001-50035

1шт.

|$39

428-U94-2311

CAB ASS'Y,(W/LOAD METER,RADIO) (TBG)

SN: 50036-51000

1шт.

|$40

428-U94-2310

CAB ASS'Y,(W/LOAD METER,RADIO) (TBG)

SN: 50001-50035

1шт.

|$$29

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-20A1.

-1шт.

1

01220-40810

SCREW

SN: 50001-@

4шт.

2

09415-01008

CAP

SN: 50001-@

3шт.

3

01220-40608

SCREW

SN: 50001-51000

4шт.

4

423-56-21960

STRIKER

SN: 50001-@

2шт.

5

01240-00825

SCREW

SN: 50001-@

4шт.

6

421-54-15760

WASHER

SN: 50001-@

4шт.

7

419-54-15690

PLATE

SN: 50001-@

4шт.

8

01010-80825

BOLT

SN: 50001-@

12шт.

9

01643-30823

WASHER

SN: 50001-@

12шт.

10

423-56-21710

CUSHION

SN: 50001-@

2шт.

11

421-56-11350

SEAL,DOOR

SN: 50001-@

2шт.

12

08037-01008

GROMMET

SN: 50001-@

2шт.

13

426-56-21990

PLUG

SN: 50001-@

2шт.
