Артикул
Название
Примечание
Количество
|$1
428-22-20100
FRONT AXLE ASS'Y
SN: 50046-UP
1шт.
|$2
428-22-20000
FRONT AXLE ASS'Y
SN: 50001-50045
1шт.
|$$3
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4400-01A0 TO F4400-08A0.
-1шт.
|$8
428-22-24100
FINAL DRIVE ASS'Y,WITH BRAKE
SN: 50046-UP
1шт.
|$9
428-22-14000
FINAL DRIVE ASS'Y,WITH BRAKE
SN: 50001-50045
1шт.
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F4400-01A0 AND F4400-02A0.
-1шт.
|$11
428-22-22100
FINAL DRIVE ASS'Y
SN: 50046-UP
1шт.
|$12
428-22-12002
FINAL DRIVE ASS'Y
SN: 50001-50045
1шт.
1
428-22-12421
GEAR
SN: 50001-UP
2шт.
2
428-22-12541
GEAR
SN: 50001-UP
2шт.
|$15
428-22-12101
CARRIER ASS'Y
SN: 50001-UP
2шт.
4
428-22-12810
BEARING
SN: 50001-UP
6шт.
6
428-22-12910
RING,SNAP
SN: 50001-UP
3шт.
7
428-22-12641
CARRIER
SN: 50001-UP
1шт.
11
01252-31230
BOLT
SN: 50001-UP
6шт.
15
428-22-12660
COVER
SN: 50046-UP
2шт.
15
428-22-12631
COVER
SN: 50001-50045
2шт.
19
425-22-12630
BUTTON
SN: 50001-UP
2шт.
20
566-16-11351
PLUG
SN: 50001-UP
2шт.
22
428-22-12710
HUB
SN: 50001-UP
2шт.
23
428-22-12130
RETAINER
SN: 50001-UP
2шт.
24
01144-62495
STUD
SN: 50001-UP
88шт.
25
428-22-12840
BEARING
SN: 50001-UP
2шт.
33
428-22-05040
SHIM ASS'Y
SN: 50001-UP
2шт.
33
428-22-12260
SHIM, 0.05MM
SN: 50001-UP
4шт.
33
428-22-12250
SHIM, 0.2MM
SN: 50001-UP
4шт.
33
428-22-12240
SHIM, 0.5MM
SN: 50001-UP
2шт.
33
428-22-12230
SHIM, 1.0MM
SN: 50001-UP
4шт.
34
428-22-12430
SPACER
SN: 50001-UP
2шт.
35
428-22-12412
SHAFT,L.H. (LONG)
SN: 50001-UP
1шт.
35
428-22-12442
SHAFT,R.H. (SHORT)
SN: 50001-UP
1шт.
Выбрано товаров: 52
