1
428-60-15112
TANK,HYDRAULIC
SN: 10001-UP
1шт.
2
421-60-11622
GAUGE,SIGHT
SN: 10001-UP
1шт.
3
07002-15234
O-RING
SN: 10001-UP
1шт.
4
02721-11617
PLUG
SN: 10001-UP
1шт.
5
19M-04-11220
CAP
SN: 10001-UP
1шт.
6
07056-18416
STRAINER
SN: 10001-UP
1шт.
7
428-60-15220
COVER,TOP
SN: 10001-UP
1шт.
8
07000-15240
O-RING
SN: 10001-UP
1шт.
9
01435-01235
BOLT
SN: 10001-UP
6шт.
10
424-60-15211
BREATHER ASS'Y
SN: 10001-UP
3шт.
10
285-62-17320
ELEMENT
SN: 10001-UP
1шт.
10
424-60-15220
RING,SNAP
SN: 10001-UP
1шт.
10
419-60-15370
O-RING
SN: 10001-UP
2шт.
10
419-60-15380
O-RING
SN: 10001-UP
1шт.
10
419-60-15390
O-RING
SN: 10001-UP
1шт.
11
427-60-15320
STRAINER
SN: 10001-UP
1шт.
12
428-60-15231
ROD
SN: 10001-UP
1шт.
13
427-60-15190
COVER
SN: 10001-UP
1шт.
14
07000-15185
O-RING
SN: 10001-UP
1шт.
15
01435-01230
BOLT
SN: 10001-UP
8шт.
16
195-60-16242
COVER
SN: 10001-UP
3шт.
17
07000-15175
O-RING
SN: 10001-UP
3шт.
18
01435-01230
BOLT
SN: 10001-UP
12шт.
19
424-60-15150
PLUG
SN: 10001-UP
3шт.
20
07000-12010
O-RING
SN: 10001-UP
3шт.
21
07063-01142
ELEMENT
SN: 10001-UP
3шт.
22
195-60-16300
VALVE ASS'Y
SN: 10001-UP
3шт.
23
195-60-16330
SPRING
SN: 10001-UP
3шт.
24
428-60-15211
COVER,BOTTOM
SN: 10001-UP
1шт.
25
07000-12120
O-RING
SN: 10001-UP
1шт.
26
01435-01230
BOLT
SN: 10001-UP
8шт.
|$31
6127-21-5601
VALVE ASS'Y
SN: 10001-UP
1шт.
27
0
BODY
SN: 10001-UP
1шт.
28
04020-00514
PIN,DOWEL
SN: 10001-UP
1шт.
29
6127-21-5620
VALVE
SN: 10001-UP
1шт.
30
6127-21-5630
PLUG
SN: 10001-UP
1шт.
31
07000-13035
O-RING
SN: 10001-UP
1шт.
32
01010-81025
BOLT
SN: 10001-UP
2шт.
33
01643-31032
WASHER
SN: 10001-UP
2шт.
34
02721-11617
PLUG
SN: 10001-UP
3шт.
35
428-60-15251
BRACKET
SN: 10001-UP
1шт.
36
01010-62450
BOLT
SN: 10001-UP
4шт.
37
01643-32460
WASHER
SN: 10001-UP
4шт.
38
01010-62460
BOLT
SN: 10001-UP
4шт.
39
01643-32460
WASHER
SN: 10001-UP
8шт.
40
01580-02419
NUT
SN: 10001-UP
4шт.
41
07378-11400
HEAD,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
1шт.
42
07000-13048
O-RING,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
1шт.
43
07371-31465
FLANGE,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
2шт.
44
07372-21235
BOLT,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
4шт.
45
01643-51232
WASHER,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
4шт.
46
07378-11200
HEAD,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
1шт.
47
07000-13038
O-RING,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
1шт.
48
07371-31255
FLANGE,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
2шт.
49
07372-21035
BOLT,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
4шт.
50
01643-51032
WASHER,(WITHOUT EMERGENCY STEERING)
SN: 10001-UP
4шт.
