Запчасти Komatsu WA600-3LK FIG. A-AA8 КОЛЕНВАЛ ДВИГАТЕЛЬ

|$0

6240-31-1100

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

6240-31-1410

GEAR, CRANK

1шт.

3

6240-31-1510

GEAR, CRANK

1шт.

4

04010-00728

KEY

1шт.

5

04020-01024

PIN

1шт.

6

6240-31-1710

SPACER

1шт.

|$7

6240-21-8100

MAIN BEARING ASSEMBLY, STANDARD

7шт.

7

NSS

BEARING, UPPER

1шт.

8

NSS

BEARING, LOWER

1шт.

|$10

6162-23-8050

THRUST BEARING ASSEMBLY

1шт.

9

NSS

BEARING, THRUST

4шт.

|$12

6240-29-8100

MAIN BEARING ASSEMBLY, UNDERSIZE 0.25MM

7шт.

7

NSS

BEARING, UPPER

1шт.

8

NSS

BEARING, LOWER

1шт.

|$15

6240-28-8100

MAIN BEARING ASSEMBLY, UNDERSIZE 0.50MM

7шт.

7

NSS

BEARING, UPPER

1шт.

8

NSS

BEARING, LOWER

1шт.

|$18

6240-27-8100

MAIN BEARING ASSEMBLY, UNDERSIZE 0.75MM

7шт.

7

NSS

BEARING, UPPER

1шт.

8

NSS

BEARING, LOWER

1шт.

|$21

6240-26-8100

MAIN BEARING ASSEMBLY, UNDERSIZE 1.00MM

7шт.

7

NSS

BEARING, UPPER

1шт.

8

NSS

BEARING, LOWER

1шт.

|$24

6162-29-8050

THRUST BEARING ASSEMBLY, OVERSIZE 0.25MM

1шт.

9

NSS

BEARING, THRUST

4шт.

|$26

6162-28-8050

THRUST BEARING ASSEMBLY, OVERSIZE 0.50MM

1шт.

9

NSS

BEARING, THRUST

4шт.

|$28

6162-27-8050

THRUST BEARING ASSEMBLY, OVERSIZE 0.75MM

1шт.

9

NSS

BEARING, THRUST

4шт.

|$30

6162-26-8050

THRUST BEARING ASSEMBLY, OVERSIZE 1.00MM

1шт.

9

NSS

BEARING, THRUST

4шт.
