Запчасти Komatsu WA600-3 A8-AA ВОЗД. КОЛЛЕКТОРS И ПОСЛЕОХЛАДИТЕЛЬ ДВИГАТЕЛЬ

1

1267 715 H1

WASHER, PLAIN (3/8 INCH)

10шт.

2

1238 756 H1

GASKET, INTAKE MANIFOLD

6шт.

3

1238 767 H1

SEAL, GROMMET

2шт.

4

1239 005 H1

RETAINER, SEAL

2шт.

5

1239 007 H1

GASKET, CONNECTION

2шт.

6

1239 759 H1

BOLT (3/8-16x1 1/4 INCH)

8шт.

7

1294 607 H1

BOLT (3/8-16x4 7/8 INCH)

3шт.

8

1239 311 H1

SEAL, RECTANGULAR RING

12шт.

9

1239 321 H1

BOLT (3/8-16x1 3/64 INCH)

4шт.

|$9

6560-41-4100

PLUG, THREADED (9/16-18 UNF)

1шт.

10

6560-51-7710

SEAL, O-RING

1шт.

11

NSS

PLUG, THREADED

1шт.

|$12

1307 040 H91

PLUG, THREADED (7/16-20 UNF)

1шт.

12

NSS

PLUG, THREADED

1шт.

13

1296 846 H1

SEAL, O-RING

1шт.

14

1295 976 H1

BOLT

14шт.

15

1296 827 H1

BOLT (3/8-16x2 3/4 INCH)

26шт.

16

1241 500 H1

BOLT (7/16-14x3 INCH)

24шт.

17

1241 501 H1

SPACER, MOUNTING

24шт.

18

1310 038 H1

GASKET, AFTERCOOLER HOUSING

2шт.

19

1310 107 H1

GASKET, AFTERCOOLER COVER

1шт.

20

1310 957 H1

BOLT

10шт.

21

1238 693 H1

GASKET, EXHAUST MANIFOLD

6шт.

22

1310 042 H1

CONNECTION, AIR CROSSOVER

1шт.

23

1310 543 H2

HOUSING, AFTERCOOLER

1шт.

24

1310 044 H1

COVER, AFTERCOOLER

1шт.

25

1310 045 H1

MANIFOLD, EXHAUST

2шт.

26

1310 731 H2

MANIFOLD, EXHAUST

1шт.

27

1310 047 H1

CORE, AFTERCOOLER

1шт.

|$29

1317 155 H1

LOCKPLATE

12шт.
