Запчасти Komatsu WA600-3 A-AA ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ

1

1237 988 H1

BOLT (5/8-11x2 IN)

1шт.

2

103 026

NUT (3/8-24 UNF)

1шт.

3

6216-24-8890

WASHER, LOCK (5/8 IN)

1шт.

4

6216-94-3440

WASHER, LOCK (3/8 IN)

1шт.

5

1238 115 H1

WASHER, PLAIN (5/8 IN)

1шт.

6

6216-94-3810

BOLT (3/8-16x3 IN)

3шт.

7

1316 699 H1

SHAFT, WATER PUMP

1шт.

8

1251 211 H1

GASKET, WATER PUMP

2шт.

|$8

1313 078 H92

PUMP, WATER

1шт.

9

1238 331 H1

SEAL, O-RING

1шт.

10

1239 109 H1

WASHER, PLAIN (3/8 IN)

2шт.

11

6216-94-3790

BOLT (3/8-16x1 1/4 IN)

1шт.

12

1239 267 H1

BOLT (3/8-16x1 1/2 IN)

1шт.

13

1239 269 H1

BOLT (3/8-16x2 IN)

1шт.

14

1239 695 H1

BRACE, WATER PUMP

1шт.

|$15

NSS

CONNECTION, WATER INLET

1шт.

15

1238 011 H1

BOLT (1/4-20x3/4 IN)

1шт.

16

6733-71-5810

WASHER, LOCK (1/4 IN)

1шт.

17

6216-84-6520

WASHER, PLAIN (1/4 IN)

1шт.

18

1238 715 H1

WASHER, SPRING

1шт.

19

6742-01-3410

ADAPTER, FILTER HEAD

1шт.

20

6731-71-4410

SHAFT, SHUT OFF VALVE

1шт.

|$22

6560-41-4100

PLUG, THREADED (9/16-18 UNF)

1шт.

21

6560-51-7710

SEAL, O-RING

1шт.

22

NSS

PLUG, THREADED

1шт.

|$25

1310 010 H91

UNION, MALE

1шт.

23

6560-51-7710

SEAL, O-RING

1шт.

24

NSS

UNION, MALE

1шт.

25

6732-81-8860

SEAL, O-RING

1шт.

|$29

1310 012 H91

ELBOW, MALE UNION

1шт.

26

6560-51-7710

SEAL, O-RING

1шт.

27

NSS

ELBOW, MALE UNION

1шт.

28

6732-81-8860

SEAL, O-RING

1шт.

29

1310 088 H1

CONNECTION, WATER INLET

1шт.

30

1310 089 H1

TUBE, WATER TRANSFER

1шт.

|$35

1239 934 H91

PLUG, THREADED (1 1/16-12 UN)

1шт.

31

6560-41-8140

SEAL, O-RING

1шт.

32

NSS

PLUG, THREADED

1шт.

33

6742-01-3390

SEAL, O-RING

1шт.

|$39

NSS

PUMP, WATER

1шт.

|$40

1310 884 H92

PUMP KIT, WATER

1шт.

34

6216-24-6210

DRAINCOCK

1шт.

35

1238 047 H1

BEARING, BALL

1шт.

36

1238 051 H1

BEARING, BALL

1шт.

37

1240 046 H1

RING, RETAINING

1шт.

38

1241 308 H1

IMPELLER, WATER PUMP

1шт.

39

1238 702 H1

RING, RETAINING

1шт.

40

1238 772 H1

SEAL, OIL

1шт.

41

1239 775 H91

SHAFT, WATER PUMP

1шт.

42

1316 116 H1

SEAL, WATER PUMP

1шт.

43

1316 750 H1

BODY, WATER PUMP

1шт.

44

1239 891 H1

PLUG, THREADED (7/8-14 UNF)

1шт.

|$52

1310 090 H91

SHAFT, WATER PUMP

1шт.

45

1238 795 H1

GEAR, WATER PUMP

1шт.

46

1239 532 H1

BEARING, THRUST

2шт.

|$55

NSS

SHAFT, WATER PUMP

1шт.

47

1238 729 H1

PLUG, OIL

1шт.

48

NSS

SHAFT, WATER PUMP

1шт.

49

1239 678 H1

RETAINER, SHAFT

1шт.

|$59

1310 092 H91

SUPPORT, WATER PUMP

1шт.

50

1238 681 H1

BUSHING

2шт.

|$61

1307 948 H1

PLUG, THREADED (5/16-24 UNF)

1шт.

51

NSS

PLUG, THREADED

1шт.

52

1307 949 H1

SEAL, O-RING

1шт.

53

NSS

SUPPORT, WATER PUMP

1шт.

54

1238 237 H1

WASHER, PLAIN (3/8 IN)

3шт.

55

1307 832 H1

SEAL, RECTANGULAR RING

1шт.

56

1307 833 H1

BOLT

6шт.

|$68

1310 339 H3

SEAL KIT

1шт.

57

NSS

SEAL, OIL

1шт.

|$70

70

-1шт.

|$71

F1 - KIT CONTAINS EXTRA PARTS NOT NEEDED FOR THIS WATER PUMP.

71

-1шт.
