Запчасти Komatsu WA600-3 U-A ТАБЛИЧКИS ШАССИ МАРКИРОВКА

|$0

426-93-21311

DECAL KIT

SN: A52001--UP

1шт.

1

NSS

DECAL - SAFETY, KEEP OUT

SN: A52001--UP

2шт.

2

NSS

DECAL - SAFETY, FRAME LOCK

SN: A52001--UP

1шт.

3

NSS

DECAL - SAFETY, RADIATOR CAP

SN: A52001--UP

1шт.

4

NSS

DECAL - SAFETY, BATTERY

SN: A52001--UP

2шт.

5

NSS

DECAL - SAFETY, HYDRAULIC TANK

SN: A52001--UP

1шт.

6

NSS

DECAL - ENGINE OIL DRAIN

SN: A52001--UP

1шт.

7

NSS

DECAL - INSTRUCTION, RADIATOR DRAIN

SN: A52001--UP

1шт.

8

NSS

DECAL - INSTRUCTION, FUEL

SN: A52001--UP

1шт.

9

427-93-11310

PLATE, CAUTION

SN: A52001--UP

1шт.

10

426-93-21310

CHART, OIL

SN: A52001--UP

1шт.

11

09805-13000

PLATE, SAFETY

SN: A52001--UP

1шт.

12

426-93-11370

PLATE, MARK, WA600

SN: A52001--UP

2шт.

13

09806-C1680

PLATE, CAUTION, KEEP A SAFE DISTANCE

SN: A52001--UP

2шт.

14

09667-A0880

PLATE, SAFETY, FAN

SN: A52001--UP

2шт.

15

09807-C1680

PLATE, CAUTION, KEEP OUT

SN: A52001--UP

2шт.

16

09960-01001

PLATE, MARK HANDLING

SN: A52001--UP

4шт.

17

09602-10040

PLATE, NAME

SN: A52001--UP

1шт.

|$18

NSS

PLATE, SERIAL NUMBER

SN: A52001--UP

1шт.

|$19

04418-13060

SCREW

SN: A52001--UP

4шт.

18

09690-C0560

PLATE, MARK, KOMATSU

SN: A52001--UP

1шт.

19

426-93-21330

DECAL, GRAY

SN: A52001--UP

2шт.

|$22

426-93-21230

PLATE, INSTRUCTION, GREASE SUPPLY

SN: A52001--UP

1шт.

20

NSS

DECAL, PIN LOCATIONS

SN: A52001--UP

1шт.

21

NSS

DECAL, AXLE LOCATIONS

SN: A52001--UP

1шт.

22

09669-0000A

DECAL, COOLANT

SN: A52001--UP

1шт.

23

426-S0-51331

DECAL, KOMATSU

SN: A52001--UP

1шт.

24

09637-30163

DECAL, NOTICE/SERV. INDICATOR

SN: A52001--UP

1шт.

25

09690-C1000

DECAL, KOMATSU

SN: A52001--UP

2шт.

26

09659-53000

DECAL, WARNING, ACCUMULATOR

SN: A52001--UP

5шт.
