Запчасти Komatsu WA600-3 T-B V-ОБРАЗН КОВШ, . CU. M. С TEETH РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

426-819-2200

BUCKET ASSEMBLY, 6.1 CU. M (SPADE NOSE WITH TEETH)

SN: A52001--UP

1шт.

2

-1шт.

1

426-847-1110

TEETH

SN: A52001--UP

10шт.

2

426-847-1130

PIN

SN: A52001--UP

10шт.

3

426-70-12142

PLATE

SN: A52001--UP

2шт.

4

02090-11475

BOLT

SN: A52001--UP

8шт.

5

01643-32460

WASHER

SN: A52001--UP

8шт.

6

02290-11422

NUT

SN: A52001--UP

8шт.

|$8

426-819-2210

BUCKET

SN: A52001--UP

1шт.

7

426-809-2210

BUCKET

SN: A52001--UP

1шт.

8

426-V65-1120

EDGE (WELDED)

SN: A52001--UP

1шт.

9

426-70-22150

PLATE (WELDED)

SN: A52001--UP

2шт.

10

426-70-22160

PLATE (WELDED)

SN: A52001--UP

2шт.

11

426-70-22250

PLATE (WELDED)

SN: A52001--UP

2шт.

12

426-847-1121

ADAPTER (WELDED)

SN: A52001--UP

8шт.

13

426-848-1121

ADAPTER (WELDED)

SN: A52001--UP

1шт.

14

426-848-1131

ADAPTER, L.H. (WELDED)

SN: A52001--UP

1шт.

15

426-70-22480

PLATE (WELDED)

SN: A52001--UP

6шт.

16

426-70-22650

PLATE (WELDED)

SN: A52001--UP

1шт.

17

426-70-22660

PLATE, L.H. (WELDED)

SN: A52001--UP

4шт.

18

426-70-22670

PLATE, R.H. (WELDED)

SN: A52001--UP

4шт.
