Запчасти Komatsu WA600-3 T-A ПРЯМ. КРОМКА КОВШ, . CU. M. С TEETH И АДАПТЕРS РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

426-807-2200

BUCKET ASSEMBLY, 6.1 CU. M. (WITH TEETH)

SN: A52001--UP

1шт.

1

426-847-1110

TEETH

SN: A52001--UP

10шт.

2

426-847-1130

PIN

SN: A52001--UP

10шт.

3

426-70-12142

PLATE

SN: A52001--UP

2шт.

4

02090-11475

BOLT

SN: A52001--UP

8шт.

5

01643-32460

WASHER

SN: A52001--UP

8шт.

6

02290-11422

NUT

SN: A52001--UP

8шт.

|$7

426-807-2210

BUCKET

SN: A52001--UP

1шт.

7

426-847-1121

ADAPTER (WELDED)

SN: A52001--UP

8шт.

8

426-848-1121

ADAPTER L.H. (WELDED)

SN: A52001--UP

1шт.

9

426-848-1131

ADAPTER R.H. (WELDED)

SN: A52001--UP

1шт.

10

426-70-22650

PLATE (WELDED)

SN: A52001--UP

9шт.

11

425-847-1170

PLATE (WELDED)

SN: A52001--UP

8шт.

12

425-847-1180

PLATE (WELDED)

SN: A52001--UP

2шт.

13

426-806-2210

BUCKET

SN: A52001--UP

1шт.

14

426-807-1120

EDGE (WELDED)

SN: A52001--UP

1шт.

15

426-806-2240

PLATE (WELDED)

SN: A52001--UP

2шт.

16

426-806-2250

PLATE (WELDED)

SN: A52001--UP

2шт.

17

426-806-2160

PLATE (WELDED)

SN: A52001--UP

2шт.
