Запчасти Komatsu WA600-3 A-AA СИСТЕМА СМАЗКИ МАСЛООХЛАДИТЕЛЬ ДВИГАТЕЛЬ

1

6742-01-5162

BOLT (3/8-16x3 1/2 IN)

8шт.

2

6216-94-3440

WASHER, LOCK (3/8 IN)

6шт.

3

864 456 R1

ELBOW, PLAIN STREET PIPE

1шт.

4

1238 237 H1

WASHER, PLAIN (3/8 IN)

4шт.

|$4

1294 664 H91

PLUG, DRAIN

1шт.

5

1238 328 H1

SEAL, O-RING

1шт.

6

1241 313 H1

PLUG, THREADED (1 3/4-18 UNS)

1шт.

7

1241 309 H1

BOLT (3/8-16x1 3/4 IN)

4шт.

8

1238 705 H1

GASKET, WATER TRANSFER CONNECTION

1шт.

9

6216-94-3670

BOLT (3/8-16x1 1/4 IN)

2шт.

10

1238 892 H1

DRAINCOCK

1шт.

11

1295 981 H1

FLANGE

1шт.

12

1241 336 H1

BOLT (3/8-16x1 5/8 IN)

2шт.

|$13

6560-41-4100

PLUG, THREADED (9/16-18 UNF)

1шт.

13

6560-51-7710

SEAL, O-RING

1шт.

14

NSS

PLUG, THREADED

1шт.

15

1239 759 H1

BOLT (3/8-16x1 1/4 IN)

10шт.

16

1241 342 H1

BOLT (3/8-16x1 7/8 IN)

9шт.

17

1239 776 H1

BOLT (3/8-16x4 IN)

14шт.

18

1307 840 H1

HOUSING, OIL COOLER

1шт.

|$20

1307 841 H3

KIT, OIL COOLER

1шт.

19

NSS

CORE, COOLER

2шт.

|$22

6742-01-5162

BOLT

4шт.

20

1238 775 H1

GASKET, OIL COOLER CORE

4шт.

21

1239 248 H2

GASKET, TORQUE CONVERTER OIL COOLER

1шт.

22

1239 878 H2

GASKET, OIL COOLER HOUSING

1шт.

23

1310 180 H1

COVER, OIL COOLER

1шт.

|$27

1239 934 H91

PLUG, THREADED (1 1/16-12 UN)

2шт.

24

6560-41-8140

SEAL, O-RING

1шт.

25

NSS

PLUG, THREADED

1шт.

|$30

1246 206 H91

PLUG, THREADED (9/16-18 UNF)

1шт.

26

6560-51-7710

SEAL, O-RING

1шт.

27

NSS

PLUG, THREADED

1шт.

28

1317 157 H1

BOLT

4шт.
