Запчасти Komatsu WA600-3 A9-AA МАСЛ. ФИЛЬТР ДВИГАТЕЛЬ

1

1239 759 H1

BOLT (3/8-16x1 1/4 IN)

6шт.

2

1307 846 H2

GASKET, FILTER COVER

1шт.

|$2

1307 847 H91

ELBOW, MALE UNION

1шт.

3

6560-51-7710

SEAL, O-RING

1шт.

4

1307 848 H1

ELBOW, MALE UNION

1шт.

5

6732-81-8860

SEAL, O-RING

1шт.

|$6

1307 849 H92

HEAD, OIL FILTER

1шт.

6

1241 103 H1

BOLT

8шт.

7

1246 127 H1

PIN, ROLL

2шт.

|$9

6560-41-4100

PLUG, THREADED

5шт.

8

6560-51-7710

SEAL, O-RING

1шт.

9

NSS

PLUG, THREADED

1шт.

10

1307 850 H1

WASHER, PLAIN

8шт.

11

1307 851 H1

SEAL, O-RING

2шт.

12

1307 852 H1

PLUNGER, FILTER HEAD

2шт.

|$15

1294 144 H91

PLUG, THREADED

2шт.

13

1294 142 H1

SEAL, O-RING

1шт.

14

NSS

PLUG, THREADED

1шт.

15

1307 855 H2

HEAD, OIL FILTER

1шт.

16

1307 856 H1

ADAPTER, FILTER HEAD

2шт.

17

1307 857 H1

SEAL, O-RING

2шт.

18

1307 858 H1

SEAL, O-RING

2шт.

19

1307 859 H1

SPRING, VALVE

2шт.

|$23

1307 860 H91

ELBOW, FEMALE ADAPTER

1шт.

20

6560-51-7710

SEAL, O-RING

1шт.

21

NSS

ELBOW, PLAIN UNION

1шт.

|$26

1307 862 H91

VALVE, CHECK

1шт.

22

1307 863 H1

VALVE, CHECK

1шт.

23

6732-81-8860

SEAL, O-RING

2шт.

|$29

1239 920 H1

PLUG, THREADED

2шт.

24

NSS

PLUG, THREADED

1шт.

25

1241 538 H1

SEAL, O-RING

1шт.

26

1307 864 H1

HOSE, CYLINDER BLOCK TO FILTER

1шт.

27

6742-01-2430

FILTER, LUBRICATING OIL

2шт.
