Запчасти Komatsu WA600-3 K-A OPERATORS СИДЕНЬЕ ВОЗД. ПОДВЕСКА С ДЖОЙСТИК РУЛЕВ. УПРАВЛЕНИЕ OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

426-S33-2190

SEAT, OPERATOR

SN: A52001--UP

1шт.

|$1

426-S33-2210

SEAT ASSEMBLY

SN: A52001--UP

1шт.

|$2

BS174328

UPPER ASSEMBLY

SN: A52001--UP

1шт.

1

NSS

BACK COVER KIT

SN: A52001--UP

1шт.

2

NSS

BACK FOAM KIT

SN: A52001--UP

1шт.

3

NSS

SEAT COVER KIT

SN: A52001--UP

1шт.

4

NSS

SEAT FOAM KIT

SN: A52001--UP

1шт.

5

NSS

SUPPORT KIT

SN: A52001--UP

1шт.

6

NSS

FRAME KIT

SN: A52001--UP

1шт.

7

BS157157

LATCH KIT

SN: A52001--UP

1шт.

8

BS162231

HEIGHT RISER KIT

SN: A52001--UP

1шт.

9

BS157117

HANDLE KIT

SN: A52001--UP

1шт.

10

BS156713

SPRING KIT

SN: A52001--UP

1шт.

11

BS174621

SUSPENSION ASSEMBLY

SN: A52001--UP

1шт.

12

BS174619

DAMPER ASSEMBLY KIT (DOUBLE DAMPER)

SN: A52001--UP

1шт.

13

BS160436

STOP KIT

SN: A52001--UP

1шт.

14

BS163954

AIR SPRING KIT

SN: A52001--UP

1шт.

15

BS164191

VALVE KIT

SN: A52001--UP

1шт.

16

BS174711

COMPRESSOR KIT

SN: A52001--UP

1шт.

17

BS164000

BEARING KIT

SN: A52001--UP

1шт.

18

BS166007

LEVER KIT

SN: A52001--UP

1шт.

19

BS174620

ADJUSTER KIT

SN: A52001--UP

1шт.

20

BS174524

COVER KIT

SN: A52001--UP

1шт.

21

BS151185

HEAD REST KIT

SN: A52001--UP

1шт.

22

BS174888

ARM REST KIT

SN: A52001--UP

1шт.

23

BS174523

HIGH RISER COVER KIT

SN: A52001--UP

1шт.

24

08055-00282

CONNECTOR

SN: A52001--UP

1шт.

25

08017-30704

CONDUIT

SN: A52001--UP

1шт.
