Запчасти Komatsu WA600-3 КОВШ КАТАЛОГИ ЗЧ

|$$1

EXCAVATING BUCKET

-1шт.

|$$2

6.1M3 BUCKET

-1шт.

|1

426-806-2100

BUCKET ASS'Y

SN: 50001-UP

1шт.

1

426-70-12142

PLATE

SN: 50001-UP

2шт.

2

02090-11475

BOLT

SN: 50001-UP

8шт.

3

01643-32460

WASHER

SN: 50001-UP

8шт.

4

02290-11422

NUT

SN: 50001-UP

8шт.

5

426-806-2110

BUCKET

SN: 50001-UP

1шт.

|6

426-806-1120

EDGE (WELDED)

SN: 50001-UP

1шт.

6

426-806-1240

PLATE (WELDED)

SN: 50001-UP

1шт.

7

426-70-12450

CORNER,L.H. (WELDED)

SN: 50001-UP

1шт.

8

426-70-12460

CORNER,R.H. (WELDED)

SN: 50001-UP

1шт.

9

426-806-2150

PLATE (WELDED)

SN: 50001-UP

2шт.

10

426-806-2160

PLATE (WELDED)

SN: 50001-UP

2шт.

|$$15

6.1M3 BUCKET{(WITH GUSSET)}

-1шт.

|11

426-806-2200

BUCKET ASS'Y

SN: 50001-UP

1шт.

11

426-70-12142

PLATE

SN: 50001-UP

2шт.

12

02090-11475

BOLT

SN: 50001-UP

8шт.

13

01643-32460

WASHER

SN: 50001-UP

8шт.

14

02290-11422

NUT

SN: 50001-UP

8шт.

|15

426-806-2220

BUCKET

SN: 50001-UP

1шт.

15

426-806-2210

BUCKET

SN: 50001-UP

1шт.

16

426-807-1120

EDGE (WELDED)

SN: 50001-UP

1шт.

17

426-806-2240

PLATE (WELDED)

SN: 50001-UP

2шт.

18

426-806-2250

PLATE (WELDED)

SN: 50001-UP

2шт.

19

426-806-2160

PLATE (WELDED)

SN: 50001-UP

2шт.

20

426-809-1320

GUSSET (WELDED)

SN: 50001-UP

2шт.
