Запчасти Komatsu WA600-1LE КОМПРЕССОР АКСЕССУАРЫ

1

1238 079 H1

NUT, HEAVY HEXAGON (7/16 - 14 UNC)

2шт.

2

120 382

WASHER, LOCK (3/8 INCH)

3шт.

3

1238 108 H1

WASHER, LOCK (7/16 INCH)

4шт.

4

1237 975 H1

CONNECTOR, MALE

1шт.

5

1240 031 H1

WASHER, PLAIN (3/8 INCH)

6шт.

6

25 544

WASHER, PLAIN (3/8 INCH)

1шт.

7

1238 548 H1

SLEEVE, SPLINE COUPLING

1шт.

8

1238 714 H1

BOLT (3/8 - 16x1 INCH)

3шт.

9

1238 760 H1

BOLT (7/16 - 14x1 3/4 INCH)

2шт.

10

1294 518 H1

BOLT (7/16 - 14x1 1/2 INCH)

2шт.

11

1239 489 H1

BRACE, AIR COMPRESSOR

1шт.

|$11

1294 722 H91

COMPRESSOR, AIR

1шт.

12

1238 112 H1

WASHER, PLAIN (5/16 INCH)

4шт.

13

1238 217 H1

PIN, PISTON

1шт.

14

1238 241 H1

SEAL, RECTANGULAR RING

1шт.

15

1238 242 H1

VALVE, EXHAUST

1шт.

16

1238 246 H1

SPRING, COMPRESSION

1шт.

17

1238 248 H1

SEAL, O RING

1шт.

18

1238 317 H1

SEAT, CPR EXHAUST VALVE

1шт.

19

1238 318 H1

VALVE, INTAKE

1шт.

20

1238 319 H1

SEAT, CPR INTAKE VALVE

1шт.

21

1238 364 H1

COVER, AIR COMPRESSOR

1шт.

22

1238 466 H1

RING, OIL PISTON

1шт.

23

1238 483 H1

PLATE, COMPRESSOR WEAR

1шт.

24

1238 504 H1

RING, COMPRESSION PISTON

1шт.

25

1238 513 H1

SPRING, VALVE

1шт.

26

1238 516 H1

CAP, UNLOADER VALVE

1шт.

27

1238 847 H1

BEARING, THRUST

1шт.

28

1239 988 H1

RING, COMPRESSION PISTON

1шт.

29

1238 971 H1

CRANKSHAFT, COMPRESSOR

1шт.

30

1238 974 H1

HUB, SPLINE COUPLING

1шт.

31

1239 100 H1

SUPPORT, AIR COMPRESSOR

1шт.

32

1239 253 H1

BOLT (3/8 - 16x1 3/16 INCH)

4шт.

33

1239 267 H1

BOLT (3/8 - 16x1 1/2 INCH)

2шт.

|$34

1239 388 H91

ROD, COMPRESSOR CONNECTIN

1шт.

34

1239 389 H1

BUSHING

1шт.

35

NSS

ROD, COMPRESSOR CONNECTIN

1шт.

36

1239 491 H1

SPRING, COMPRESSION

1шт.

37

1295 840 H1

PLUG, PIPE (1/16 NPT)

1шт.

38

1294 101 H1

SEAL, O RING

1шт.

39

1239 787 H1

SEAL, O RING

1шт.

40

1239 814 H1

PISTON, COMPRESSOR

1шт.

41

1294 069 H1

BODY, UNLOADING VALVE

1шт.

42

1239 832 H1

GASKET, AIR COMPRESSOR

1шт.

43

1310 183 H1

GASKET, AIR COMPRESSOR

1шт.

44

1307 361 H1

HEAD, COMPRESSOR

1шт.

45

1295 842 H1

SCREW, DRIVE

4шт.

46

1307 240 H1

RING, RETAINING

2шт.

47

1295 841 H1

BOLT (5/16 - 18x2 3/4INCH)

4шт.

48

1307 362 H1

WASHER, PLAIN

2шт.

49

1307 363 H1

SCREW, SOCKET HEAD CAP

2шт.

50

1307 364 H1

NAMEPLATE

1шт.

51

1307 239 H1

GASKET, SUPPORT

1шт.

52

NSS

BUSHING

1шт.

53

NSS

CRANKCASE, COMPRESSOR

1шт.

54

1307 267 H1

GASKET, AIR COMPRESSOR

1шт.

|$56

1310 144 H91

CONNECTOR, MALE

1шт.

55

1307 820 H1

SEAL, O RING

1шт.

56

1310 145 H1

CONNECTOR, MALE

1шт.

|$$60

-1шт.

|$60

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$61

ASSEMBLIES CATALOG.

-1шт.
