Запчасти Komatsu WA600-1LE STARTER ЭЛЕКТРИКА

|$6

LA 0 848

MOTOR ASSY, CRANKING

1шт.

1

1211 395 H1

BUSHING, CE FRAME

1шт.

2

1211 396 H1

ARMATURE, MOTOR

1шт.

3

1211 397 H1

COIL ASSY, FIELD

1шт.

4

1211 269 H1

STUD, TERMINAL

1шт.

5

1211 283 H1

BUSHING, LEVER HOUSING

1шт.

6

1233 259 H1

CLUTCH, POSITORK

1шт.

|$11

1288 448 H91

HOUSING ASSY, DRIVE

1шт.

7

1211 288 H1

BUSHING, HOUSING

1шт.

8

1211 277 H1

PLUG, WICK

1шт.

9

1302 333 H1

WICK, FELT

1шт.

10

NSS

HOUSING, DRIVE

1шт.

|$16

1288 455 H1

PLUG, BOLT HOLE

6шт.

11

347 360 R1

O-RING

1шт.

|$18

1296 920 H1

BOLT, MOUNTING - 5/16NCx1-1/2

3шт.

|$19

1296 921 H1

BOLT, MOUNTING - 5/16NCx7/8

3шт.

12

1211 399 H1

BRUSH ASSY, MOTOR

6шт.

|$21

1211 292 H1

SCREW, MOUNTING

6шт.

|$22

1211 401 H91

PLATE ASSY, BRUSH

1шт.

13

1211 400 H1

HOLDER AND SPRING, BRUSH

6шт.

14

NSS

PLATE, BRUSH

1шт.

|$25

1211 279 H1

SCREW, BRUSH, PLATE

6шт.

15

1211 290 H1

PLUNGER, SOLENOID

1шт.

16

1211 291 H1

BOOT, PLUNGER

1шт.

17

1210 073 H1

SPRING, PLUNGER

1шт.

18

1211 289 H1

LEVER, SHIFT

1шт.

19

1211 356 H1

WASHER, SPACER

1шт.

20

1211 286 H1

WASHER, BRAKE

1шт.

21

1211 402 H1

WASHER, THRUST

1шт.

22

1277 066 H1

CABLE, TERMINAL

1шт.

23

1211 267 H1

NUT, TERMINAL STUD

2шт.

24

19 839 R1

NUT, ADJUSTING

1шт.

25

NSS

SHOE, POLE

6шт.

|$34

1245 108 H1

SCREW, POLE SHOE

12шт.

26

1211 265 H1

WASHER, INSULATION

2шт.

27

1211 266 H1

WASHER, PLAIN

2шт.

28

1211 280 H1

WASHER, INSULATION

2шт.

29

1210 070 H1

WASHER, PLUNGER

1шт.

|$39

1211 281 H1

PACKAGE, TERMINAL INSULATOR

1шт.

30

NSS

BUSHING, TERMINAL STUD

1шт.

31

NSS

INSULATOR, STUD

1шт.

|$42

1211 264 H1

PACKAGE, TERMINAL BUSHING

1шт.

32

NSS

SUPPORT, INSULATOR

1шт.

33

NSS

WASHER, INSULATION

`

1шт.

34

1211 151 H1

GASKET, INSPECTION PLUG

2шт.

35

1211 398 H1

SOLENOID

1шт.

|$47

1302 329 H1

BOLT, MOUNTING -1/4NCx1/2

4шт.

36

1211 271 H1

INSULATOR, POLE SHOE

6шт.

37

1302 331 H1

O-RING

2шт.

38

355 967 R1

O-RING

1шт.

39

352 219 R1

O-RING

1шт.

40

1210 066 H1

PLUG, INSPECTION

2шт.

41

1211 277 H1

PLUG, WICK

2шт.

42

1302 333 H1

WICK, FELT

1шт.

43

1210 074 H1

RETAINER, SPRING

1шт.

44

1210 072 H1

RETAINER, SPRING

1шт.

45

1211 285 H1

SEAL, OIL

1шт.

46

1211 152 H1

SHAFT, SHIFT LEVER

1шт.

47

213 262 R1

RING, RETAINING

2шт.

48

1211 276 H1

WICK, FELT

1шт.

49

NSS

FRAME, CE

1шт.

|$62

NSS

BOLT, MOUNTING

8шт.

50

102 238

NUT, TERMINAL STUD JAM - 1/2NC

2шт.

51

NSS

WASHER, LOCK

1шт.

52

NSS

INSULATOR, FIELD COIL

1шт.

53

NSS

HOUSING, ARMATURE

1шт.

54

NSS

HOUSING, LEVER

1шт.

|$68

NSS

BOLT, MOUNTING

7шт.

55

1211 292 H1

SCREW, FIELD COIL ATTACHING

2шт.

56

1302 332 H1

CONNECTOR, TERMINAL TO SWITCH

1шт.

57

NSS

INSULATOR, BRUSH PLATE

1шт.

58

NSS

NUT, TERMINAL

1шт.

59

1241 597 H1

WIRE, GROUND

1шт.

|$74

-1шт.

|$75

F1 - PACKAGE CONTAINS PARTS NOT REQUIRED FOR THIS CRANKING MOTOR.

-1шт.

|$76

-1шт.

|$77

R1 - REMANUFACTURED ASSEMBLE AVAILABLE. REFER TO REMANUFACTURED

-1шт.

|$78

ASSEMBLIES CATALOG

-1шт.
