Запчасти Komatsu WA600-1LE ТОПЛИВН. ВПРЫСК ТРУБЫ ТОПЛИВН. СИСТЕМА

1

1307 994 H1

TUBE, FUEL SUPPLY - RAIL

1шт.

2

1307 995 H1

TUBE, FUEL SUPPLY - RAIL

1шт.

3

1307 996 H1

TUBE, FUEL SUPPLY - TIMING

1шт.

4

1307 997 H1

TUBE, FUEL SUPPLY - TIMING

1шт.

|$4

1307 998 H91

MANIFOLD, FUEL

1шт.

|$5

1295 576 H91

PLUG, THREADED

2шт.

5

1239 669 H1

SEAL, O-RING

2шт.

6

1310 097 H1

PLUG, THREADED

2шт.

|$8

1307 999 H91

PLUG, THREADED

4шт.

7

6736-51-8710

SEAL, O-RING

1шт.

8

1310 000 H1

PLUG, THREADED

1шт.

9

1310 001 H1

MANIFOLD, FUEL

1шт.

10

1238 234 H1

WASHER, PLAIN

24шт.

11

1307 820 H1

SEAL, O-RING

22шт.

12

1310 002 H1

BOLT

24шт.

13

1310 003 H1

TUBE, FUEL SUPPLY - RAIL

1шт.

14

1310 004 H1

TUBE, FUEL SUPPLY - TIMING

1шт.

|$17

1310 005 H91

TEE, MALE UNION

2шт.

15

1310 006 H1

TEE, MALE UNION

1шт.

16

6732-81-8860

SEAL, O-RING

3шт.

17

1310 007 H1

CONNECTION, FUEL BLOCK

1шт.

18

1310 008 H1

SCREW, SOCKET HEAD CAP

8шт.

19

1310 009 H1

WASHER, PLAIN

8шт.

|$23

1267 723 H91

NIPPLE, COUPLING

2шт.

20

1296 280 H1

NIPPLE, COUPLING

1шт.

21

1246 119 H1

O-RING

1шт.

22

1307 351 H91

COVER, PROTECTIVE

1шт.

|$27

1310 010 H91

UNION, MALE

2шт.

23

6731-61-7280

UNION, MALE

1шт.

24

1246 119 H1

O-RING

1шт.

25

6732-81-8860

SEAL, O-RING

1шт.

|$31

1310 012 H91

ELBOW, MALE UNION

2шт.

26

1310 013 H1

ELBOW, MALE UNION

1шт.

27

1246 119 H1

O-RING

1шт.

28

6732-81-8860

SEAL, O-RING

1шт.

|$35

1310 014 H1

UNION, MALE

2шт.

29

6731-61-7280

UNION, MALE

2шт.

30

6735-21-4160

O-RING

1шт.

31

1307 820 H1

SEAL, O-RING

1шт.

32

1310 015 H1

CONNECTION, FUEL BLOCK

2шт.

|$40

1310 016 H91

MANIFOLD, FUEL

1шт.

|$41

1295 576 H91

PLUG, THREADED

2шт.

33

1239 669 H1

SEAL, O-RING

1шт.

34

1310 097 H1

PLUG, THREADED

1шт.

|$44

1307 999 H91

PLUG, THREADED

4шт.

35

6736-51-8710

SEAL, O-RING

1шт.

36

1310 000 H1

PLUG, THREADED

1шт.

37

1310 017 H1

MANIFOLD, FUEL

1шт.

38

6732-81-8860

SEAL, O-RING

2шт.
