Запчасти Komatsu WA600-1LE LUBE МАСЛ. НАСОС СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

1238 745 H1

O-RING, LUBE PUMP BODY

2шт.

2

1238 785 H1

RING, RECTANGULAR SEALING

1шт.

3

6216-94-3790

BOLT (3/8 - 16x1 1/4 INCH)

3шт.

|$3

1307 866 H91

PUMP, LUBRICATING OIL

1шт.

4

1238 073 H1

BOLT (3/8 - 16x4 1/4 INCH)

1шт.

5

6216-94-3440

WASHER, LOCK (3/8 INCH)

1шт.

6

1239 270 H1

BOLT (3/8 - 16x2 1/4 INCH)

3шт.

7

1307 867 H1

GASKET, LUBE OIL PUMP

1шт.

8

1240 067 H1

DOWEL, PIN

1шт.

9

1238 166 H1

DOWEL, DIAMOND

1шт.

10

1238 796 H1

GEAR, PUMP

1шт.

|$11

1307 868 H91

BODY, PUMP

1шт.

11

1240 036 H1

BUSHING, PUMP

2шт.

12

1307 869 H1

BODY, PUMP

1шт.

|$14

1307 870 H91

GEAR, SHAFT

1шт.

13

1307 871 H1

GEAR, PUMP

1шт.

14

1307 872 H1

SHAFT, PUMP DRIVE

1шт.

|$17

1307 873 H91

GEAR, SHAFT

1шт.

15

1307 871 H1

GEAR, LUBRICATING OIL PUMP

1шт.

16

1307 874 H1

SHAFT, IDLER

1шт.

|$20

1307 875 H91

COVER, PUMP

1шт.

17

1240 036 H1

BUSHING, PUMP

2шт.

18

1307 876 H1

RING, RETAINING

1шт.

19

1307 877 H1

PLUG, RETAINER

1шт.

20

1307 878 H1

SPRING, COMPRESSION

1шт.

21

1307 879 H1

PLUNGER, PRESSURE REGULATOR

1шт.

22

1307 880 H1

COVER, PUMP

1шт.

|$30

-1шт.

|$28

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$29

ASSEMBLIES CATALOG.

-1шт.
