Запчасти Komatsu WA600-1LC СМАЗЫВ. НАСОС СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

|$0

1250 684 H91

PUMP, LUBRICATING OIL

1шт.

1

1238 025 H1

BOLT - 3/8-16 X 2 1/2

2шт.

2

1238 035 H1

BOLT - 3/8-16 X 2 3/4

1шт.

4

186 285

BOLT - 3/8-16 X 4

1шт.

5

1240 067 H1

DOWEL, PIN

1шт.

6

1238 166 H1

DOWEL, DIAMOND

1шт.

7

1238 657 H1

GASKET, LUBE OIL PUMP

1шт.

8

1238 796 H1

GEAR, LUBRICATING OIL PUMP

1шт.

9

1238 342 H1

GEAR, LUBRICATING OIL PUMP

2шт.

11

120 382

WASHER, LOCK

4шт.

12

1238 662 H1

PLUNGER, PRESSURE REGULATOR

1шт.

14

1238 654 H1

SHAFT, IDLER

1шт.

15

1267 116 H1

SPRING, COMPRESSION

1шт.

16

1239 889 H1

PLUG, RETAINER

1шт.

|$15

1238 655 H91

BODY ASSY, LUBRICATING OIL PUMP

1шт.

17

NSS

BODY, LUBRICATING OIL PUMP

1шт.

18

1240 036 H1

BUSHING

4шт.

20

1238 658 H1

SHAFT, LUBE OIL PUMP

1шт.

21

1241 346 H91

COVER, LUBE OIL PUMP

1шт.

23

140 483 H

BOLT, W/WASHER - 3/8-16 X 1 1/4

3шт.

25

1238 745 H1

O-RING

2шт.

26

1238 785 H1

O-RING

1шт.
