Запчасти Komatsu WA600-1LC PROВОЗДУХОВОДЫ GRAPHICS - ИСПАНИЯ МАРКИРОВКАS

Схема запчастей Komatsu WA600-1LC - PROВОЗДУХОВОДЫ GRAPHICS - ИСПАНИЯ МАРКИРОВКАS
31
9
8
27
21
16
29
28
29
5
3
22
36
11
7
40
R
U
BB
Z
T
Y
M
V

Артикул

Название

Примечание

Количество

|$0

425-93-A1000

PRODUCT GRAPHICS - SPANISH

1шт.

1

425-V00-A150

PRODUCT GRAPHIC, SERVICE CHART

1шт.

2

419-V00-1120

PRODUCT GRAPHIC, CAUTION - STARTING THE MACHINE

1шт.

3

419-V00-1130

PRODUCT GRAPHIC, WARNING - FRAME LOCKING BAR

1шт.

5

419-V00-1140

PRODUCT GRAPHIC, CAUTION - ENGINE FAN

2шт.

6

419-V00-1150

PRODUCT GRAPHIC, WARNING - OPERATOR'S MANUAL

1шт.

7

09162-01000

PRODUCT GRAPHIC, DANGER - NO ENTRANCE

2шт.

8

09668-01000

PRODUCT GRAPHIC, WARNING - PRESSURIZED COOLING

-1шт.

|$9

SYSTEM

1шт.

9

644 865 C3

PRODUCT GRAPHIC, CAUTION - HYDRAULIC RESERVOIR

1шт.

10

1124 687 C2

PRODUCT GRAPHIC, IMPORTANT - DIESEL FUEL

1шт.

11

09152-01000

PRODUCT GRAPHIC, CAUTION, DRAIN AIR TANKS

1шт.

12

09685-00003

PRODUCT GRAPHIC, WORK EQUIPMENT CONTROL LEVER LOCK

2шт.

13

09683-11070

PRODUCT GRAPHIC, MAIN SWITCH

1шт.

14

421-93-11132

PRODUCT GRAPHIC, WORK EQUIPMENT CONTROL LEVER

1шт.

15

09690-C0630

PRODUCT GRAPHIC,

1шт.

16

09690-C0224

PRODUCT GRAPHIC,

2шт.

17

NSS

PRODUCT GRAPHIC, SERIAL NO. PLATE

1шт.

18

04418-13060

SCREWS FOR SERIAL NO. PLATE

4шт.

19

419-V00-1260

PRODUCT GRAPHIC, CAUTION TORQUE CONVERT OIL TEMP

1шт.

20

419-V00-1130

PRODUCT GRAPHIC, TRANSMISSION OIL LEVEL

1шт.

21

419-V00-1121

PRODUCT GRAPHIC, BATTERY CAUTION

2шт.

22

419-V00-1210

PRODUCT GRAPHIC, CAUTION BRAKE OIL

1шт.

23

426-V00-1230

PRODUCT GRAPHIC, FUSE IDENTIFICATION

1шт.

24

426-V00-A220

PRODUCT GRAPHIC, FUSE IDENTIFICATION

1шт.

25

426-V00-A210

PRODUCT GRAPHIC, RELAY POSITION

1шт.

26

426-V00-1120

PRODUCT GRAPHIC, ELECTRONIC DISPLAY PANEL

1шт.

27

NOT USED

-1шт.

28

426-93-11370

PRODUCT GRAPHIC, MARK MODEL

2шт.

29

426-93-11140

PRODUCT GRAPHIC, SIDE STRIPE

2шт.

30

426-93-11140

PRODUCT GRAPHIC, SIDE STRIPE

2шт.

31

NOT USED

-1шт.

32

426-V00-1140

PRODUCT GRAPHIC, REMOTE GREASE - REAR

1шт.

33

425-V00-1170

PRODUCT GRAPHIC, REMOTE GREASE - FRONT

1шт.

34

426-V00-1130

PRODUCT GRAPHIC, REMOTE GREASE FRONT

1шт.

35

09653-01000

PRODUCT GRAPHIC, HYDRAULIC TANK AIR PRESSURE

1шт.

36

421-V00-1180

PRODUCT GRAPHIC, ENGINE OIL DRAIN

1шт.

37

421-V00-1190

PRODUCT GRAPHIC, RADIATOR DRAIN

1шт.

38

418-V00-1160

PRODUCT GRAPHIC, CAUTION - ETHER START

1шт.

39

1170 726 C2

PRODUCT GRAPHIC, EMERGENCY EXIT

1шт.

40

939 372 C3

PRODUCT GRAPHIC, CAUTION LADDER

2шт.

Выбрано товаров: 41
