Запчасти Komatsu WA600-1L ТРАНСМИССИЯ 1 МУФТА -

|$0

TRANSMISSION ASSEMBLY (SEE PG 02-012)

-29шт.

1

426-15-12121

SHAFT, 1st CLUTCH

1шт.

2

426-15-12920

BUSHING

1шт.

3

426-15-11560

COVER

1шт.

4

01010-50820

BOLT

3шт.

5

01602-20825

WASHER, LOCK

3шт.

6

426-15-11550

COLLAR

1шт.

7

04064-08530

RING, RETAINING

1шт.

8

426-15-12340

CARRIER, 1st CLUTCH

1шт.

9

07018-11405

RING, SEAL

2шт.

10

426-15-12430

GEAR

4шт.

11

426-15-12960

BEARING

4шт.

12

426-15-19440

WASHER, THRUST

8шт.

|$13

426-15-00160

SHAFT ASSEMBLY

4шт.

13

NSS

SHAFT

1шт.

14

145-14-11320

PLUG

1шт.

15

04025-00624

PIN, SPRING

4шт.

16

426-15-12250

GEAR

1шт.

17

426-15-12860

BUSHING

1шт.

18

06000-06920

BEARING

1шт.

19

04064-01030

RING, RETAINING

1шт.

20

04077-00140

RING, RETAINING

1шт.

21

04070-00160

RING, RETAINING

1шт.

22

426-15-12611

GEAR, RING

1шт.

23

198-15-22810

DISC

3шт.

24

426-15-12720

PLATE

2шт.

25

425-15-12880

SPRING

18шт.

26

234-15-15230

SPRING

12шт.

27

426-15-12750

PISTON, 1st CLUTCH

1шт.

28

426-15-19220

RING, SEAL - 1st CLUTCH PISTON

1шт.

29

426-15-11130

HOUSING, 1st CLUTCH

1шт.

30

155-15-12770

PIN

6шт.

31

426-15-19210

RING, SEAL - 1st CLUTCH HOUSING

1шт.

32

GEAR, RING - 3rd CLUTCH (SEE PG 02-036)

-29шт.

33

CAGE, UPPER TRANSFER OUTPUT GEARS (SEE PG 02-022)

-29шт.

N/I

SERVICE KIT, TRANSMISSION (SEE PG 02-058)

-29шт.

|$38

-1шт.

|$37

F1 - INCLUDED IN SERVICE KIT 426-15-05200.

-1шт.

|$39

-1шт.
