Запчасти Komatsu WA600-1L ТРАНСМИССИЯ 3 МУФТА -

|$0

TRANSMISSION ASSEMBLY (SEE PG 02-012)

-29шт.

1

426-15-12330

CARRIER, 3rd CLUTCH

1шт.

2

426-15-12430

GEAR

4шт.

3

426-15-12960

BEARING

4шт.

4

09233-13220

WASHER, THRUST

8шт.

|$5

426-15-00150

SHAFT ASSEMBLY

4шт.

5

NSS

SHAFT

1шт.

6

07043-00108

PLUG

1шт.

7

04025-00620

PIN, SPRING

4шт.

8

426-15-12240

GEAR

1шт.

9

04064-09530

RING, RETAINING

1шт.

10

426-15-12620

GEAR, RING

1шт.

11

426-15-11140

HOUSING, 3rd CLUTCH

1шт.

12

04020-01434

PIN, DOWEL

12шт.

13

426-15-19210

RING, SEAL - 3rd CLUTCH HOUSING

1шт.

14

426-15-12740

PISTON, 3rD CLUTCH

1шт.

15

175-15-59250

RING, SEAL - 3rd CLUTCH PISTON

1шт.

16

198-15-22810

DISC

3шт.

17

426-15-12720

PLATE

2шт.

18

175-15-42880

SPRING

18шт.

19

234-15-15230

SPRING

12шт.

20

RING, RETAINING - 1st CLUTCH (SEE PG 02-038)

-29шт.

21

PIN, 1st CLUTCH (SEE PG 02-038)

-29шт.

22

SHAFT, 1st CLUTCH (SEE PG 02-038)

-29шт.

N/I

SERVICE KIT, TRANSMISSION (SEE PG 02-058)

-29шт.

|$27

-1шт.

|$26

F1 - INCLUDED IN SERVICE KIT 426-15-05200.

-1шт.

|$28

-1шт.
