Запчасти Komatsu WA600-1L ТРАНСМИССИЯ 2 МУФТА -

|$0

TRANSMISSION ASSEMBLY (SEE PG 02-012)

-29шт.

|$1

41E-15-00180

HOUSING ASSEMBLY, 2nd CLUTCH

1шт.

1

NSS

HOUSING, 2nd CLUTCH

1шт.

2

234-15-12790

SCREW

1шт.

3

526-15-11450

PLUG

1шт.

4

426-15-12830

COLLAR

1шт.

5

01252-30630

BOLT

3шт.

6

426-15-19270

RING, SEAL

2шт.

7

06000-06926

BEARING

1шт.

8

04070-00130

RING, RETAINING

1шт.

9

04071-00180

RING, RETAINING

1шт.

10

426-15-11210

HOUSING, 2nd CLUTCH

1шт.

11

103-15-12811

RING, SEAL - 2nd CLUTCH HOUSING

1шт.

12

426-15-12780

PISTON, 2nd CLUTCH

1шт.

13

562-15-19220

RING, SEAL - 2nd CLUTCH PISTON

1шт.

14

426-15-12911

PLATE, SPRING

3шт.

15

04070-00155

RING, RETAINING

1шт.

16

06000-06919

BEARING

1шт.

17

424-15-12710

DISC

5шт.

18

287-15-12990

PLATE

4шт.

19

426-15-12270

HUB

1шт.

20

06000-06924

BEARING

1шт.

21

04064-09530

RING, RETAINING

1шт.

22

01010-51230

BOLT

22шт.

23

01643-31232

WASHER

22шт.

24

287-15-12920

SPRING

5шт.

25

GEAR, RING - 4th CLUTCH (SEE PG 02-030)

-29шт.

26

CARRIER, 3rd CLUTCH (SEE PG 02-036)

-29шт.

N/I

SERVICE KIT, TRANSMISSION (SEE PG 02-058)

-29шт.

|$31

-1шт.

|$30

F1 - INCLUDED IN SERVICE KIT 426-15-05200.

-1шт.

|$32

-1шт.
