Запчасти Komatsu WA600-1L КОРПУС ГИДРОТРАНСФОРМАТОРА -

|$0

711-59-00010

TORQUE CONVERTER, COMPLETE ASSEMBLY

1шт.

1

711-59-13111

HOUSING

1шт.

|$2

01010-51235

BOLT, MOUNT HOUSING TO ENGINE

16шт.

|$3

01643-31232

WASHER

16шт.

2

07043-00617

PLUG

2шт.

3

04530-11222

BOLT, EYE - LIFTING

1шт.

4

711-17-13220

COVER, HOUSING

1шт.

|$7

01010-51025

BOLT, MOUNT HOUSING COVER

4шт.

|$8

01602-21030

WASHER, LOCK

4шт.

5

711-17-13230

GASKET, HOUSING COVER

1шт.

|$10

711-59-16600

VALVE ASSEMBLY

1шт.

|$11

01010-51085

BOLT, MOUNT VALVE ASSEMBLY

3шт.

|$12

01602-21030

WASHER, LOCK

3шт.

6

711-59-16610

BODY, VALVE

1шт.

7

07042-20108

PLUG

2шт.

8

711-59-16620

SPOOL

1шт.

9

562-13-16460

VALVE

1шт.

10

562-15-16110

SPRING

1шт.

11

562-13-16470

VALVE

1шт.

12

562-15-16630

SPRING

1шт.

13

711-20-16740

COVER, VALVE

2шт.

|$21

01010-51025

BOLT, MOUNT VALVE COVER

4шт.

|$22

01602-21030

WASHER, LOCK

4шт.

14

07000-63038

O-RING, VALVE COVER

2шт.

15

07000-62014

O-RING, VALVE BODY

2шт.

16

07000-63035

O-RING, VALVE BODY

2шт.

17

09607-05080

PLATE, NAME (LIMITED SUPPLY)

1шт.

|$27

04418-03760

SCREW, MOUNT NAME PLATE

4шт.

18

426-13-19110

O-RING, HOUSING SEAL

1шт.

N/I

711-59-05010

SERVICE KIT, TORQUE CONVERTER

-1шт.

|$32

-1шт.

|$31

F1 - INCLUDED IN SERVICE KIT 711-59-05010.

-1шт.

|$33

-1шт.
