Запчасти Komatsu WA600-1L КОВШ V-ОБРАЗН ROCK .YD / .9Mю 7-

1

426-831-1210

BUCKET, SPADE NOSE ROCK 6.5YD/4.9mі

1шт.

2

426-70-12132

PLATE (WELDED)

2шт.

3

426-70-12122

EDGE (WELDED)

1шт.

4

426-70-12153

PLATE, L.H. (WELDED)

2шт.

5

426-70-12163

PLATE, R.H. (WELDED)

1шт.

6

426-70-12183

PLATE (WELDED)

2шт.

7

NSS

PLATE (WELDED)

2шт.

8

426-70-12192

PLATE (WELDED)

2шт.

9

426-70-12411

PLATE (WELDED)

1шт.

10

426-70-12391

PLATE (WELDED)

8шт.

11

426-70-12481

PLATE (WELDED)

10шт.

12

426-70-12481

PLATE (WELDED)

6шт.

13

426-847-1121

ADAPTER (WELDED)

8шт.

14

426-848-1121

ADAPTER, L.H. (WELDED)

1шт.

15

426-848-1131

ADAPTER, R.H. (WELDED)

1шт.

16

426-847-1110

TOOTH

10шт.

17

426-847-1130

PIN

10шт.

18

426-70-12142

PLATE

2шт.

19

02090-11475

BOLT

8шт.

20

01643-32460

WASHER

8шт.

21

02290-11422

NUT

8шт.
