Запчасти Komatsu WA600-1 V-ОБРАЗН КОВШ (С ЗУБЬЯМИ) КАТАЛОГИ ЗЧ

|$$1

5.4M3 BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

|1

426-70-12910

BUCKET ASS'Y

SN: 10865-UP

1шт.

1

426-70-12114

BUCKET

SN: 10865-UP

1шт.

2

426-70-12132

PLATE (WELDED)

SN: 10865-UP

2шт.

3

426-70-12122

EDGE (WELDED)

SN: 10865-UP

1шт.

4

426-70-12153

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

5

426-70-12163

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

6

426-70-12192

PLATE (WELDED)

SN: 10865-UP

2шт.

7

426-70-12421

PLATE (WELDED)

SN: 10865-UP

2шт.

8

426-70-12470

GUARD,L.H. (WELDED)

SN: 10865-UP

1шт.

9

426-70-12470

GUARD,R.H. (WELDED)

SN: 10865-UP

1шт.

10

426-70-12232

PLATE (WELDED)

SN: 10865-UP

2шт.

11

426-70-12411

PLATE (WELDED)

SN: 10865-UP

1шт.

12

426-70-12391

PLATE (WELDED)

SN: 10865-UP

8шт.

13

426-848-1110

PLATE (WELDED)

SN: 10865-UP

10шт.

14

426-70-12142

PLATE

SN: 10865-UP

2шт.

15

02090-11475

BOLT

SN: 10865-UP

8шт.

16

02290-11422

NUT

SN: 10865-UP

8шт.

17

01643-32460

WASHER

SN: 10865-UP

8шт.

|$$20

FOR LOAD AND CARRY

-1шт.

|$$21

7.5M3 BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

|1

426-T67-1900

BUCKET ASS'Y

SN: 10800-UP

1шт.

1

426-T67-1910

BUCKET

SN: 10800-UP

1шт.

2

426-70-12132

PLATE (WELDED)

SN: 10800-UP

2шт.

3

426-70-12122

EDGE (WELDED)

SN: 10800-UP

1шт.

4

426-70-12153

PLATE,L.H. (WELDED)

SN: 10800-UP

1шт.

5

426-70-12163

PLATE,R.H. (WELDED)

SN: 10800-UP

1шт.

6

426-70-12192

PLATE (WELDED)

SN: 10800-UP

2шт.

7

426-T67-1180

PLATE (WELDED)

SN: 10800-UP

2шт.

8

426-70-12470

GUARD (WELDED)

SN: 10800-UP

1шт.

9

426-70-12470

GUARD (WELDED)

SN: 10800-UP

1шт.

10

426-T67-1270

PLATE (WELDED)

SN: 10800-UP

2шт.

11

426-70-12411

PLATE (WELDED)

SN: 10800-UP

1шт.

12

426-70-12391

PLATE (WELDED)

SN: 10800-UP

8шт.

13

426-848-1110

PLATE (WELDED)

SN: 10800-UP

10шт.

14

426-70-12142

PLATE

SN: 10800-UP

2шт.

15

02090-11475

BOLT

SN: 10800-UP

8шт.

16

01643-32460

WASHER

SN: 10800-UP

8шт.

17

02290-11422

NUT

SN: 10800-UP

8шт.

|$$40

ROCK BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

14

426-70-12142

PLATE

SN: 10865-UP

2шт.

15

02090-11475

BOLT

SN: 10865-UP

8шт.

16

01643-32460

WASHER

SN: 10865-UP

8шт.

17

02290-11422

NUT

SN: 10865-UP

8шт.

18

426-819-1210

BUCKET ASS'Y

SN: 10865-UP

1шт.

19

426-70-12132

PLATE (WELDED)

SN: 10865-UP

2шт.

20

426-70-12122

EDGE (WELDED)

SN: 10865-UP

1шт.

21

426-70-12153

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

22

426-70-12163

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

23

426-70-12192

PLATE (WELDED)

SN: 10865-UP

2шт.

24

426-70-12183

PLATE (WELDED)

SN: 10865-UP

2шт.

25

426-70-12232

PLATE (WELDED)

SN: 10865-UP

2шт.

26

426-70-12411

PLATE

SN: 10865-UP

1шт.

27

426-70-12391

PLATE

SN: 10865-UP

8шт.

|$$55

HEAVY DUTY BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

28

426-V65-1210

BUCKET

SN: 10865-UP

1шт.

29

426-V65-1160

PLATE

SN: 10865-UP

2шт.

30

426-V65-1120

EDGE (WELDED)

SN: 10865-UP

1шт.

31

426-V65-1140

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

32

426-V65-1150

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

33

426-V65-1170

PLATE (WELDED)

SN: 10865-UP

2шт.

34

426-70-12470

GUARD (WELDED)

SN: 10865-UP

2шт.

35

426-V65-1230

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

36

426-V65-1240

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

37

426-V65-1250

PLATE (WELDED)

SN: 10865-UP

1шт.

38

426-V65-1250

PLATE (WELDED)

SN: 10865-UP

1шт.

39

426-V65-1250

PLATE (WELDED)

SN: 10865-UP

1шт.

40

426-V65-1220

PLATE (WELDED)

SN: 10865-UP

3шт.

41

426-V65-1180

PLATE (WELDED)

SN: 10865-UP

2шт.

42

426-70-12192

PLATE (WELDED)

SN: 10865-UP

2шт.

43

425-V65-1241

PLATE (WELDED)

SN: 10865-UP

1шт.

44

425-V65-1251

PLATE (WELDED)

SN: 10865-UP

6шт.
