Запчасти Komatsu WA600-1 V-ОБРАЗН КОВШ КАТАЛОГИ ЗЧ

|$$1

ROCK BUCKET

-1шт.

1

426-809-1312

BUCKET ASS'Y

SN: 10865-UP

1шт.

2

426-70-12132

PLATE (WELDED)

SN: 10865-UP

2шт.

3

426-70-12122

EDGE (WELDED)

SN: 10865-UP

1шт.

|3

426-70-12240

EDGE (WELDED)

SN: 10865-UP

1шт.

4

426-70-12153

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

5

426-70-12163

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

6

426-70-12183

PLATE (WELDED)

SN: 10865-UP

2шт.

7

426-809-1320

GUSSET (WELDED)

SN: 10865-UP

2шт.

8

426-70-12192

PLATE (WELDED)

SN: 10865-UP

2шт.

9

426-70-12142

PLATE

SN: 10865-UP

2шт.

10

02090-11475

BOLT

SN: 10865-UP

8шт.

11

01643-32460

WASHER

SN: 10865-UP

8шт.

12

02290-11422

NUT

SN: 10865-UP

8шт.

|$$15

ROCK BUCKET{(WITH TIRE GUARD)}

-1шт.

13

426-809-1512

BUCKET ASS'Y

SN: 10865-UP

1шт.

14

426-70-12132

PLATE (WELDED)

SN: 10865-UP

2шт.

15

426-70-12122

EDGE (WELDED)

SN: 10865-UP

1шт.

|15

426-70-12240

EDGE (WELDED)

SN: 10865-UP

1шт.

16

426-70-12153

PLATE,L.H. (WELDED)

SN: 10865-UP

1шт.

17

426-70-12163

PLATE,R.H. (WELDED)

SN: 10865-UP

1шт.

18

426-70-12421

PLATE (WELDED)

SN: 10865-UP

2шт.

19

426-70-12470

GUARD,L.H. (WELDED)

SN: 10865-UP

1шт.

20

426-70-12441

GUARD,R.H. (WELDED)

SN: 10865-UP

1шт.

21

426-809-1320

GUSSET (WELDED)

SN: 10865-UP

2шт.

22

426-70-12192

PLATE (WELDED)

SN: 10865-UP

2шт.
