Запчасти Komatsu WA500-7 U-A ПЛАСТИНЫ И ТАБЛИЧКИS МАРКИРОВКА

|$0

425-93-41680

PLATE ASSEMBLY

1шт.

1

09653-03001

PLATE, WARNING, HIGH TEMPERATURE

1шт.

2

09668-03001

PLATE, WARNING, HOT WATER

3шт.

3

09667-03001

PLATE, CAUTION, ROTATING OBJECT

2шт.

4

09805-13000

PLATE, CAUTION, HOOD

1шт.

5

09812-03000

PLATE, DANGER, KEEP A SAFE DISTANCE

2шт.

6

425-93-41350

PLATE, AIR CLEANER COVER LOCK

1шт.

|$7

425-93-41690

PLATE ASSEMBLY

1шт.

7

09808-03000

PLATE, WARNING, BATTERY CABLES

2шт.

8

09162-23000

PLATE, DANGER, KEEP OFF

2шт.

9

09161-23000

PLATE, WARNING, ARTICULATION LOCK

1шт.

10

09637-30163

PLATE, SERVICE INSTRUCTION, AIR CLEANER

1шт.

11

6217-71-6470

PLATE, FUEL FILTER REPLACE

1шт.

12

09667-53000

PLATE, CAUTION, ROTATING OBJECT

1шт.

13

09642-13000

PLATE, SERVICE INSTRUCTION, ENGINE COOLANT AF-NAC

1шт.

14

20Y-00-41340

PLATE, PRE FILTER CAUTION

1шт.

15

09805-03000

PLATE, CAUTION, FENDER

2шт.

16

09652-31241

PLATE, CAUTION, DIESEL FUEL

1шт.

17

09669-0000A

PLATE, SYMBOL, COOLANT FILLER

1шт.

18

425-03-43560

PLATE, RADIATOR RESERVOIR TANK LEVEL

1шт.

19

6245-81-9410

PLATE, FUEL FEED PUMP TIMER

1шт.

20

NSS

PLATE ASSEMBLY, PARKING BRAKE EMERGENCY RELEASE 1

1шт.

21

NSS

PLATE ASSEMBLY, PARKING BRAKE EMERGENCY RELEASE 2

1шт.

22

NSS

PLATE ASSEMBLY, GREASING 1

1шт.

23

NSS

PLATE ASSEMBLY, GREASING 2

1шт.

24

NSS

PLATE ASSEMBLY, GREASING 3

1шт.

25

NSS

PLATE ASSEMBLY, RADIATOR DRAIN, INSIDE

1шт.

26

NSS

PLATE ASSEMBLY, RADIATOR DRAIN

1шт.

27

NSS

PLATE ASSEMBLY, ENGINE OIL DRAIN

1шт.

28

NSS

PLATE ASSEMBLY, FUEL TANK DRAIN

1шт.

|$30

425-93-41710

PLATE ASSEMBLY

1шт.

29

09960-01601

MARK, LIFT POINT AND TIE DOWN POINT MARKS

4шт.

30

425-93-41280

LUBRICATION CHART

1шт.

31

09807-C1201

PLATE, DANGER, KEEP OUT UNDER WORK EQUIPMENT

2шт.

32

09659-53000

PLATE, WARNING, EXPLOSION HAZARD

4шт.

33

09664-30011

PLATE, DANGER, BATTERY

2шт.

34

425-93-43110

PLATE, WA500-7, L.H.

1шт.

35

425-93-43120

PLATE, WA500-7, R.H.

1шт.

36

425-93-43140

PLATE, STRIPE

1шт.

37

09690-P1120

PLATE, KOMATSU LOGO

2шт.

38

09602-10042

PLATE, NAME

1шт.

39

04418-13060

SCREW

4шт.

40

14X-98-35181

PLATE, REFLECTOR

2шт.

41

09963-03001

TAG, DANGER, DO NOT OPERATE

1шт.

N/I

423-93-51272

PLATE, MULTI-FUNCTION MONO LEVER (WITHOUT PSC SWITCH)

1шт.

|$45

45

-1шт.

|$46

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

46

-1шт.
