Запчасти Komatsu WA500-7 A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ

|$0

6261-31-1200

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

6150-31-1130

KEY

1шт.

3

6210-31-1120

GEAR

1шт.

|$4

6261-21-8000

BEARING ASSEMBLY

1шт.

|$5

6261-21-8010

BEARING, MAIN (STANDARD)

7шт.

|$6

6261-29-8010

BEARING, MAIN (UNDERSIZE 0.25 MM)

7шт.

|$7

6261-28-8010

BEARING, MAIN (UNDERSIZE 0.50 MM)

7шт.

|$8

6261-27-8010

BEARING, MAIN (UNDERSIZE 0.75 MM)

7шт.

|$9

6261-26-8010

BEARING, MAIN (UNDERSIZE 1.00 MM)

7шт.

4

NSS

BEARING, UPPER (STANDARD)

1шт.

|$11

NSS

BEARING, UPPER (UNDERSIZE 0.25 MM)

1шт.

|$12

NSS

BEARING, UPPER (UNDERSIZE 0.50 MM)

1шт.

|$13

NSS

BEARING, UPPER (UNDERSIZE 0.75 MM)

1шт.

|$14

NSS

BEARING, UPPER (UNDERSIZE 1.00 MM)

1шт.

5

NSS

BEARING, LOWER (STANDARD)

1шт.

|$16

NSS

BEARING, LOWER (UNDERSIZE 0.25 MM)

1шт.

|$17

NSS

BEARING, LOWER (UNDERSIZE 0.50 MM)

1шт.

|$18

NSS

BEARING, LOWER (UNDERSIZE 0.75 MM)

1шт.

|$19

NSS

BEARING, LOWER (UNDERSIZE 1.00 MM)

1шт.

N/I

6210-21-8050

BEARING, THRUST (STANDARD)

1шт.

N/I

6210-29-8050

BEARING, THRUST (OVERSIZE 0.25 MM)

1шт.

N/I

6210-28-8050

BEARING, THRUST (OVERSIZE 0.50 MM)

1шт.

N/I

6210-27-8050

BEARING, THRUST (OVERSIZE 0.75 MM)

1шт.

N/I

6210-26-8050

BEARING, THRUST (OVERSIZE 1.00 MM)

1шт.

6

NSS

BEARING, THRUST (STANDARD)

3шт.

|$26

NSS

BEARING, THRUST (OVERSIZE 0.25 MM)

3шт.

|$27

NSS

BEARING, THRUST (OVERSIZE 0.50 MM)

3шт.

|$28

NSS

BEARING, THRUST (OVERSIZE 0.75 MM)

3шт.

|$29

NSS

BEARING, THRUST (OVERSIZE 1.00 MM)

3шт.

7

04020-01228

PIN, DOWEL

1шт.

8

6211-31-1420

PIN

1шт.
