Запчасти Komatsu WA500-7 H-8A ГИДР. НАСОС. СИЛОВАЯ ПЕРЕДАЧА НАСОС (/) ГИДРАВЛИКА

|$0

705-52-30A60

PUMP ASSEMBLY, GEAR (SAR63+50)

1шт.

|$1

705-22-36480

PUMP, GEAR (SAR63)

1шт.

1

705-17-03021

BRACKET ASSEMBLY

1шт.

|$3

705-17-03352

BUSHING

2шт.

2

705-17-03220

CARRIER ASSEMBLY

1шт.

|$5

705-17-03352

BUSHING

2шт.

3

705-17-03630

PLATE

1шт.

4

705-17-03640

PLATE

1шт.

5

705-17-03443

RING, BACK-UP

2шт.

6

705-17-03473

SEAL

2шт.

7

705-17-03381

O-RING

2шт.

8

705-17-03870

PLATE

1шт.

9

705-17-03811

SEAL, OIL

1шт.

10

04065-05220

RING, SNAP

1шт.

11

705-17-36010

GEAR CASE

1шт.

12

705-17-36431

GEAR, DRIVE

1шт.

13

705-17-36511

GEAR, DRIVEN

1шт.

14

04020-01228

PIN, DOWEL

4шт.

15

01253-61615

BOLT, HEXAGON SOCKET HEAD

4шт.

16

01643-51645

WASHER

4шт.

|$20

20

-1шт.

|$21

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

21

-1шт.
