Запчасти Komatsu WA500-7 H-7A ГИДР. НАСОС. НАСОС ВЕНТИЛЯТОРА (/) ГИДРАВЛИКА

|$15

PUMP ASSEMBLY (SEE FIG. H0210-14A0 )

0

-1шт.

1

708-2L-25480

FILTER

2шт.

2

708-2L-25490

O-RING

2шт.

3

708-1S-19710

ORIFICE

1шт.

4

01252-60635

BOLT, HEXAGON SOCKET HEAD

3шт.

5

01252-60650

BOLT, HEXAGON SOCKET HEAD

1шт.

6

07000-B3040

O-RING

1шт.

7

04020-00616

PIN, DOWEL

2шт.

8

708-3S-14240

PLUG

1шт.

9

708-3S-14261

PLUG

1шт.

10

07002-61223

O-RING

2шт.

11

708-1S-19930

PLUG

1шт.

12

723-60-22230

RING, BACK-UP

1шт.

13

07000-B2016

O-RING

1шт.

14

07002-62434

O-RING

1шт.

|$16

15

-1шт.

|$17

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

16

-1шт.
