Запчасти Komatsu WA500-7 H-A ГИДР. НАСОС. НАСОС РУЛЕВ. УПРАВЛ-Я (/) ГИДРАВЛИКА

|$17

PUMP ASSEMBLY (SEE FIG. H0210-09A0 ) .PUMP SUBASSEMBLY (SEE FIG. H0210-09A0 )

0

-1шт.

1

708-1W-43310

BLOCK, CYLINDER

1шт.

2

708-1W-43120

PLATE, VALVE

1шт.

3

720-68-19610

PIN

1шт.

4

708-1W-43130

SEAT

2шт.

5

708-1W-43140

SPRING

1шт.

6

04065-04818

RING, SNAP

1шт.

7

708-1W-43320

GUIDE, RETAINER

1шт.

8

708-3T-13360

PIN

3шт.

9

708-1W-43341

RETAINER, SHOE

1шт.

10

708-1U-13310

PISTON SUBASSEMBLY

9шт.

11

708-1W-44170

PISTON

1шт.

12

708-1W-44140

SPRING

1шт.

13

708-1U-14240

SCREW

2шт.

14

07000-B2011

O-RING

2шт.

15

01643-31232

WASHER

2шт.

16

01582-11210

NUT

2шт.

|$18

17

-1шт.

|$19

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

18

-1шт.
